AOBOCAM Mini 1080p HD зымсыз WiFi жашыруун коопсуздук камерасы A12 колдонуучу колдонмосу

1. Киришүү

Thank you for choosing the AOBOCAM Mini 1080p HD Wireless WiFi Hidden Security Camera A12. This manual provides essential information for setting up, operating, and maintaining your camera. Please read it thoroughly before use to ensure optimal performance and safety.

The AOBOCAM A12 is a compact and discreet security solution designed for indoor surveillance. It features 1080p HD video, a 120° wide-angle lens, night vision capabilities, and intelligent motion detection. With dual WiFi and Bluetooth connectivity, setup is quick and easy, allowing remote monitoring via a dedicated mobile application.

2. Продукт бүтүп калдыview

2.1 Пакеттин мазмуну

• Mini Camera (A12)
• USB кабели
• Instruction Manual
• Mounting Bracket / Support

2.2 Негизги өзгөчөлүктөрү

• Кош байланыш: Supports both WiFi and Bluetooth for faster and simpler pairing.
• 1080p HD Video: Crystal-clear 1080p resolution with an upgraded high-resolution sensor and premium lenses.
• 120° Ultra Wide-Angle Lens: Кеңири чагылдырат view of your environment.
• Жакшыртылган түнкү көрүнүш: Integrated infrared LEDs provide clear footage in low-light conditions up to 10 meters.
• Акылдуу кыймылды аныктоо: Identifies changes in the scene and sends instant notifications to your mobile device.
• Ийкемдүү сактоо параметрлери: Supports local storage via SD card (8-256GB, not included) and optional cloud storage. Loop recording ensures continuous coverage.
• 24/7 Мониторинг: Built-in battery provides up to 90 minutes of continuous operation, or connect directly to a power source for uninterrupted surveillance.
• Компакт дизайн: Miniature size (30x30x30mm) for discreet placement.

Figure 1: AOBOCAM A12 Mini Camera and its compact size, demonstrating remote viewжөндөмдүүлүктөрүн.

3. Орнотуу колдонмосу

3.1 Камераны заряддоо

Before initial use, fully charge the camera using the provided USB cable. Connect the USB cable to the camera's charging port and a standard USB power adapter (not included). The charging indicator light will typically show the charging status.

3.2 Микро SD картаны кыстаруу (кошумча)

If you plan to use local storage, insert a compatible Micro SD card (8GB to 256GB, Class 10 or higher recommended) into the designated slot on the camera. Ensure the camera is powered off before inserting or removing the SD card.

3.3 Downloading the Mobile Application

Издөө the official AOBOCAM application on your smartphone's app store (iOS App Store or Google Play Store). Download and install the application.

3.4 Pairing the Camera with Your Smartphone

1. Power on the AOBOCAM A12 camera.
2. Open the installed mobile application on your smartphone.
3. Follow the in-app instructions to add a new device. The camera supports both WiFi and Bluetooth for a faster connection process.
4. Select your 2.4 GHz WiFi network and enter the password when prompted. (Note: 5 GHz WiFi networks are not supported).
5. Once connected, the camera's indicator light will confirm successful pairing.

Figure 2: The compact design of the AOBOCAM A12 allows for discreet placement in various indoor settings.

4. Иштөө нускамалары

4.1 Live View жана Жаздыруу

After successful pairing, open the mobile application to access the live video feed from your camera. You can initiate manual recordings, take snapshots, and view реалдуу убакыт footage.

4.2 Кыймылды аныктоо жана эскертүүлөр

The AOBOCAM A12 features intelligent motion detection. When movement is detected, the camera will automatically begin recording and send a notification to your smartphone.

• Иштетүү/Өчүрүү: Adjust motion detection sensitivity and enable/disable alerts within the app settings.
• Иш-чараны ойнотуу: Access recorded motion events through the app's event log or playback feature.

Figure 3: The camera's motion detection feature alerts you to activity in the monitored area.

4.3 Түнкү көрүнүш

The camera automatically switches to night vision mode in low-light conditions, utilizing its infrared LEDs to provide clear black-and-white video footage.

4.4 Two-Way Talk (if supported by app)

If the mobile application supports two-way audio, you can use this feature to communicate through the camera. Press and hold the microphone icon in the app to speak, and release to listen.

Figure 4: Two-way talk allows real-time communication through the camera.

4.5 Электр энергиясын башкаруу

The camera can operate on its internal battery for up to 90 minutes. For continuous 24/7 surveillance, connect the camera to a power source using the USB cable and a power adapter. The app may also offer remote power ON/OFF functionality.

Figure 5: The camera offers extended standby time and remote power control for flexible use.

5. Техникалык тейлөө

• Тазалоо: Камера линзасын жана корпусун тазалоо үчүн жумшак, кургак чүпүрөктү колдонуңуз. Абразивдүү тазалоочу каражаттарды же эриткичтерди колдонбоңуз.
• Жайгашкан жери: Ensure the camera is placed in a stable, dry indoor environment, away from direct sunlight, extreme temperatures, and moisture.
• Программалык камсыздоонун жаңыртуулары: Regularly check the mobile application for any available firmware updates for your camera to ensure optimal performance and security.
• SD Card башкаруу: If using an SD card, periodically back up important recordings and format the card through the app to maintain performance.

6. Кыйынчылыктарды

• Камера WiFi'га туташпай жатат:
  • Ensure your WiFi network is 2.4 GHz. The camera does not support 5 GHz networks.
  • Check that the WiFi password is entered correctly.
  • Move the camera closer to your WiFi router.
  • Камераны жана роутериңизди өчүрүп күйгүзүңүз.
• Видеонун сапаты начар:
  • Check your internet connection speed. A stable connection is required for HD streaming.
  • Камера объективинин таза жана чаң же тактар ​​жок экенин текшериңиз.
• Motion detection alerts not received:
  • Колдонмонун жөндөөлөрүндө кыймылды аныктоо иштетилгенин текшериңиз.
  • Check app notification settings on your smartphone to ensure they are not blocked.
  • Adjust motion detection sensitivity if alerts are too frequent or too few.
• SD карта жаздырбай жатат:
  • SD карта туура салынганын жана толуп калбаганын текшериңиз.
  • Format the SD card through the app.
  • Check if the SD card is damaged or incompatible (use Class 10 or higher).
• Камера күйбөй жатат:
  • Ensure the camera is fully charged or connected to a working power source.
  • Башка USB кабелин же кубат адаптерин колдонуп көрүңүз.

7. Техникалык шарттар

8. Кепилдик жана колдоо

For warranty information and technical support, please refer to the contact details provided with your product packaging or visit the official AOBOCAM webсайт. Сатып алуу квитанциясын кепилдик дооматтары үчүн сатып алуунун далили катары сактаңыз.

If you encounter any issues not covered in this manual, please contact AOBOCAM customer service for assistance.
