1. Продукт бүтүп калдыview
The COCOCAM ZY-C3 is an advanced 2K wireless outdoor security camera designed for comprehensive property surveillance. It features dual lenses, intelligent AI detection, and flexible power options, ensuring reliable monitoring and ease of use.
Figure 1.1: COCOCAM ZY-C3 Camera and Solar Panel
Негизги өзгөчөлүктөрү:
- Dual PIR & Smart Motion Detection: Two PIR sensors for simultaneous monitoring of different angles, reducing false alarms with human detection and customizable alarm zones.
- 2K 3MP Dual Lens & Wide Pan-Tilt Coverage: Crystal-clear 2K video quality with 355° horizontal pan and 90° vertical tilt for multi-angle surveillance.
- Intelligent AI Analysis: Effectively detects people, cars, animals, and packages (premium feature).
- 100% Wireless & Two-Way Audio: Easy installation with no wiring, and remote two-way communication.
- Long-lasting Power: Equipped with a 10000mAh rechargeable battery and a 6W solar panel for continuous operation.
- Bluetooth Pairing & Storage Options: Quick Bluetooth setup, supports TF card (up to 128GB, not included) and cloud storage.
- Түнкү көрүнүш: Clear night vision up to 25m in white light and 30m in infrared.
2. Орнотуу колдонмосу
2.1 Пакеттин мазмуну
Орнотуудан мурун, бардык компоненттердин бар экендигин текшериңиз:
- COCOCAM ZY-C3 Camera Unit
- Күн панели (6 Вт)
- Монтаждоо кронштейндери жана буроолор
- USB заряддоо кабели
- User Manual
2.2 Физикалык орнотуу
The camera is designed for outdoor use and is 100% wireless, making installation flexible. Choose a location with good Wi-Fi signal and direct sunlight for the solar panel.
- Камераны орнотуу: Secure the camera to a wall or suitable surface using the provided mounting bracket and screws. Ensure the camera has a clear view сиз көзөмөлдөгүңүз келген аймак.
- Күн панелин орнотуу: Install the solar panel in a location that receives maximum direct sunlight throughout the day. Connect the solar panel cable to the camera's charging port.
Figure 2.1: Camera and Solar Panel Installation Example
Figure 2.2: Solar Panel Connection for Continuous Power
2.3 App Pairing and Configuration
Download the COCOCAM app from your device's app store (compatible with Android/iOS). Follow these steps to pair your camera:
- Колдонмону жүктөп алып, орнотуу: Издөө "COCOCAM" in the App Store or Google Play Store and install it.
- Эсеп түзүү: Колдонмону ачып, жаңы каттоо эсебин каттаңыз же сизде мурунтан эле бар болсо кириңиз.
- Түзмөк кошуу: Tap the "Add Device" or "+" icon in the app. Select "Camera on Battery" or the appropriate camera type.
- Камераны күйгүзүү: Ensure your camera is powered on.
- Bluetooth жупташууда: The camera supports quick Bluetooth pairing. Follow the on-screen prompts in the app to connect via Bluetooth.
- Wi-Fi конфигурациясы: Select your 2.4GHz Wi-Fi network (5GHz is not supported) and enter the password. The camera will connect to your network.
- Аяктоо: Туташкандан кийин, камераңызга ат коюп, мониторингди баштасаңыз болот.
Figure 2.3: App Pairing Step 1 - Add Device
Figure 2.4: App Pairing Step 2 - Select Device Type
Figure 2.5: App Pairing Step 3 - Wi-Fi Configuration
3. Иштөө нускамалары
3.1 Live View жана Pan-Tilt башкаруусу
Access the live feed from your camera via the COCOCAM app. The dual lenses provide a wide field of view, and the pan-tilt function allows you to adjust the camera's perspective remotely.
- Pan-Tilt Control: Use the directional controls within the app to rotate the camera horizontally (355°) and vertically (90°).
- Кош линза View: The app displays feeds from both lenses, allowing you to monitor two different areas simultaneously or get a broader perspective.
Figure 3.1: Pan-Tilt Functionality
Figure 3.2: Dual Zone Monitoring
3.2 Акылдуу аныктоо жана эскертүүлөр
The camera utilizes dual PIR sensors and AI analysis to accurately detect motion and identify specific objects, sending instant alerts to your device.
- Dual PIR Detection: Advanced motion detection system that triggers recording and alerts based on heat and movement, reducing false alarms from environmental factors.
- AI Analysis: The camera can differentiate between people, vehicles, animals, and packages, providing more relevant notifications.
- Customizable Alarm Zones: Камералардын ичиндеги белгилүү бир аймактарды коюңуз view кыймылды аныктоо активдүү болушу керек болгон жерде.
Figure 3.3: AI-Powered Object Recognition
Figure 3.4: Smart PIR Detection with Alarms
3.3 Эки тараптуу аудио
Коноктор менен баарлашыңыз же орнотулган микрофонду жана динамикти колдонуп, бузукуларды алдын алыңыз.
- Сүйлөө: Камера аркылуу сүйлөшүү үчүн колдонмодогу микрофон сүрөтчөсүн таптаңыз.
- Угуу: The camera's microphone picks up audio from the monitored area.
3.5-сүрөт: Эки тараптуу аудио байланыш
3.4 Түнкү көрүнүш
The camera provides clear surveillance even in low-light conditions with its advanced night vision capabilities.
- Түнкү көрүнүш: Up to 25 meters with white light illumination.
- Инфракызыл түнкү көрүнүш: Up to 30 meters in complete darkness.
Figure 3.6: 2K Color Night Vision
3.5 Сактоо параметрлери
Видео жаздыруу жана сактооtage using either a local TF card or cloud storage services.
- TF карта сактоо: Supports up to 128GB TF card (not included). Insert the card into the designated slot on the camera.
- Булуттагы сактагыч: Offers 6-second event recording and 7-day loop coverage (subscription may be required for extended features).
Figure 3.7: TF Card and Cloud Storage Options
4. Техникалык тейлөө
4.1 Электр энергиясын башкаруу
The camera is designed for low power consumption and continuous operation with its solar panel.
- Батареяны заряддоо: The 10000mAh battery is charged by the 6W solar panel. Ensure the solar panel is clean and receives adequate sunlight.
- Кол менен заряддоо: If solar charging is insufficient (e.g., during prolonged cloudy periods), you can manually charge the camera using a 5V 2A power adapter (8-10 hours for full charge).
4.2 Аба ырайына туруктуулук
The camera has an IP66 waterproof rating, making it suitable for various outdoor weather conditions.
4.1-сүрөт: IP66 суу өткөрбөөчүлүк
4.3 TF Card Management
For optimal performance, it is recommended to format the TF card before its first use in the camera.
5. Кыйынчылыктарды
5.1 Байланыш маселелери
- Камера Wi-Fi'га туташпай жатат: Wi-Fi тармагыңыз 2.4 ГГц экенин текшериңиз. Камера 5 ГГц Wi-Fi колдобойт. Камеранын жайгашкан жериндеги Wi-Fi сигналынын күчүн текшериңиз.
- App not finding camera during pairing: Ensure Bluetooth is enabled on your phone and the camera is powered on and in pairing mode.
5.2 Кубаттоо жана кубаттоо маселелери
- Күн панели заряддалбай жатат: Verify the solar panel is clean and positioned to receive direct sunlight. Check the connection cable between the solar panel and the camera.
- Батареянын бат түгөнүп калышы: Reduce the frequency of motion detection alerts or live view access. Ensure the solar panel is providing sufficient charge.
5.3 Image/Video Quality Issues
- бүдөмүк сүрөттөр: Clean the camera lenses. Ensure there are no obstructions in front of the camera.
- Poor night vision: Ensure the night vision LEDs are not obstructed. Check for strong light sources directly facing the camera at night.
5.4 Жалган сигналдар
- Too many alerts: Adjust the motion detection sensitivity in the app. Define specific alarm zones to exclude areas with frequent irrelevant motion (e.g., swaying trees).
- AI detection not working as expected: Ensure the camera's firmware is up to date. Review the AI detection settings in the app.
6. Техникалык шарттар
| Өзгөчөлүк | Спецификация |
|---|---|
| Бренд | КОКОКАМ |
| Модель номери | ZY-C3 |
| Тtage | 5 вольт |
| Күч | 6 Watts (Solar Panel) |
| Өлчөмдөрү (L x W x Y) | 11 x 15 x 17.5 сантиметр |
| Сууга туруктуулук деңгээли | IP66 (Суу өткөрбөйт) |
| Байланыш технологиясы | Bluetooth, Wi-Fi (2.4 ГГц) |
| Натыйжалуу дагы эле чечим | 3 мегапиксел |
| Батареянын курамы | Литий |
| Заряддалуучу батарея | Yes (10000mAh) |
| Видео жаздыруу чечими | 1296p (2K) |
| Каналдардын саны | 2 (Dual Lens) |
| Материал | Акрилонитрил бутадиен стирол (ABS) |
7. Кепилдик жана колдоо
COCOCAM offers a Өмүр бою кепилдик for this product, ensuring long-term reliability and customer satisfaction.
For technical support, troubleshooting assistance, or warranty claims, please contact COCOCAM customer service through the official website or your purchase platform. Refer to the contact information provided with your product packaging or on the COCOCAM brand store page.
