1. Киришүү
Thank you for choosing the Tronsmart KH02 Kids Wireless Headphones. This manual provides detailed instructions for setting up, operating, maintaining, and troubleshooting your headphones to ensure a safe and enjoyable listening experience for children.
2. Кутуда эмне бар
- 1 x Tronsmart KH02 Wireless Kids Headphones
- 1 x Кепилдик картасы
- 1 x User Manual
- 1 x Type-C кабели
- 1 x Aux-in кабели
3. Продукт бүтүп калдыview
The Tronsmart KH02 headphones are designed for children, featuring a volume limit function, long battery life, and a comfortable, durable design. They support both wireless (Bluetooth) and wired (3.5mm Aux-in) connections.
Image: Tronsmart KH02 Kids Wireless Headphones in Princess Pink, showcasing жалпы дизайн.
Видео: Бүттүview of the Tronsmart KH02 Wireless Kids Headphones, highlighting features like portability, durability, comfortable fit, safe volume control, long playtime, and dual mode (wireless/wired).
4. Орнотуу жана туташуу
4.1 Наушниктерди заряддоо
Before first use, fully charge the headphones. Connect the provided Type-C cable to the charging port on the headphones and the other end to a USB power source. A full charge takes approximately 2 hours and provides up to 45 hours of playtime.
Image: A child enjoying music with Tronsmart KH02 headphones, emphasizing the 45-hour battery life.
4.2 Зымсыз (Bluetooth) байланышы
- Күйгүзүү: Press and hold the 'Multifunction' button for 2 seconds to turn on the headphones. The indicator light will flash, indicating pairing mode.
- Bluetooth иштетүү: Түзмөгүңүздө (смартфон, планшет ж.б.) Bluetooth жөндөөлөрүнө өтүп, Bluetooth иштетилгенин текшериңиз.
- Жупташуу: Издөө "Tronsmart KH02" in the list of available devices and select it to connect. Once connected, the indicator light will stop flashing.
Video: Demonstrates how to operate the Tronsmart KH02 Wireless Kids Headphones, including power on, Bluetooth pairing, music control, and call management.
Image: Tronsmart KH02 headphones demonstrating wireless connectivity with a smartphone.
4.3 Wired Connection (3.5mm Aux-in)
To use the headphones in wired mode, simply plug the provided 3.5mm Aux-in cable into the headphone's audio jack and the other end into your device's 3.5mm audio output. This mode is useful when the battery is depleted or for devices without Bluetooth connectivity.
Image: Children using Tronsmart KH02 headphones in both wireless and wired modes.
5. Иштөө нускамалары
5.1 Негизги башкаруу каражаттары
- Күйгүзүү/өчүрүү: Press and hold the 'Multifunction' button for 2 seconds.
- Музыканы ойнотуу/тындыруу: Press the 'Multifunction' button once.
- Көлөмү: Press the 'Volume +' button once.
- Үнүн азайтуу: Press the 'Volume -' button once.
- Кийинки трек: Press and hold the 'Volume +' button for 2 seconds.
- Мурунку трек: Press and hold the 'Volume -' button for 2 seconds.
- Чалууга жооп берүү/аяктоо: Press the 'Multifunction' button once.
- Чакырууну четке кагуу: Double-press the 'Multifunction' button.
5.2 Volume Limit Control
The headphones feature a three-level volume control switch to protect children's hearing. You can select between 74dB, 85dB, and 93dB depending on the environment and age of the child. Adjust the switch located on the earcup to your desired volume limit.
Image: Visual representation of the volume limit settings (74dB for sleep, 85dB for study, 93dB for travel).
5.3 Built-in HD Microphone
The integrated HD microphone allows for clear, hands-free calls, making the headphones suitable for online learning or communication.
Image: Child using headphones with a laptop, highlighting the built-in HD microphone.
6. Техникалык тейлөө
6.1 Тазалоо
Wipe the headphones with a soft, dry cloth. Do not use abrasive cleaners or solvents. Keep the charging port and audio jack free of dust and debris.
6.2 Сактоо
The headphones feature a foldable design for compact storage and portability. When not in use, fold them to save space and protect them from damage. Store in a cool, dry place away from extreme temperatures.
Image: Features of the Tronsmart KH02 headphones, including adjustable headband, soft ear pads, eco-friendly materials, and foldable design.
Image: Children demonstrating the durability and flexibility of the headphones' headband.
7. Кыйынчылыктарды
- Кулакчындар күйбөй жатат: Наушниктердин толук заряддалганын текшериңиз.
- Түзмөк менен жупташтыруу мүмкүн эмес:
- Түзмөгүңүздө Bluetooth иштетилгенин жана гарнитура жупташтыруу режиминде экенин текшериңиз.
- Наушниктерди түзмөгүңүзгө жакыныраак жылдырыңыз.
- Try resetting the headphones by pressing and holding the 'Multifunction' and 'Volume +' buttons simultaneously for 5 seconds.
- Үн жок же үнү төмөн:
- Наушниктердин жана туташкан түзмөгүңүздүн үнүнүн деңгээлин текшериңиз.
- Кулакчындар туура туташтырылганын текшериңиз (Bluetooth же зымдуу).
- Verify the volume limit switch is set to an appropriate level.
- Чалуу сапаты начар: Ensure the microphone is not obstructed and you are in an area with good signal strength.
8. Техникалык шарттар
| Өзгөчөлүк | Деталь |
|---|---|
| Модель аты | KH02 |
| Байланыш технологиясы | Зымсыз (Bluetooth 5.3) |
| Наушник уясы | 3.5 мм Джек |
| Көлөмдүн чеги | 74дБ, 85дБ, 93дБ |
| Батареянын иштөө мөөнөтү | 45 саатка чейин |
| Заряддоо убактысы | 2 саат |
| Камтылган микрофон | Yes (HD Mic) |
| Бүктөлүүчү дизайн | Ооба |
| Жөнгө салынуучу баш боосу | Yes (Four levels) |
| Earpad Material | Imitation Protein Leather |
| Материал | Eco-friendly Plastic |
| Элемент Салмагы | 5.9 унция |
| Продукциянын өлчөмдөрү | 6.17 x 2.89 x 7.07 дюйм |
| Bluetooth диапазону | 49 Фут |
| Frequency Response | 20 Гц |
| Сезимталдуулук | 93 дБ |
| Импеданс | 8 Ом |
9. Кепилдик жана колдоо
The Tronsmart KH02 Kids Wireless Headphones come with a Warranty Card. Please refer to the card for specific warranty terms and conditions. For product support, technical assistance, or further inquiries, please contact Tronsmart customer service through their official webпродукт сатылып алынган сайт же сатуучу.
