1. Киришүү
Thank you for choosing the YOUENKITY 500ML Large Essential Oil Diffuser. This ultrasonic cool mist humidifier is designed to enhance your home environment with long-lasting aromatherapy, quiet operation, and customizable lighting. With its generous 500ML capacity, it can provide continuous mist for over 20 hours, covering an area of up to 480 sq ft. This manual provides detailed instructions for safe and effective use of your new diffuser.
Image: The YOUENKITY 500ML Large Essential Oil Diffuser operating quietly on a bedside table, emitting mist and soft light, with a sleeping person in the background, illustrating its quiet operation and benefit for sleep.
2. Пакеттин мазмуну
Сураныч, пакеттин мазмунун текшерип, бардык буюмдар бар экенин текшериңиз:
- YOUENKITY 500ML Essential Oil Diffuser Unit
- Кубаттуу адаптер
- Алыстан башкаруу
- User Manual
- Support Legs (3 pieces, if not pre-installed)
3. Орнотуу
- Install Support Legs (if applicable): If your diffuser did not come with the support legs pre-installed, gently insert each of the three legs into the designated slots on the bottom of the diffuser. Rotate clockwise until you hear a "click" sound, ensuring the more inclined side of the support leg faces inward.
- Капкакты алып салуу: Диффузордун үстүнкү капкагын акырын көтөрүңүз.
- Суу менен толтуруу: Fill the water tank with clean tap water up to the maximum water level line indicated inside the tank. Do not overfill.
- Эфир майларын кошуу: Add 3-5 drops of your preferred essential oil directly into the water tank. Adjust the amount based on desired fragrance intensity.
- Капкакты алмаштыруу: Place the lid back onto the diffuser, ensuring it is securely seated.
- Туташуу кубаты: Plug the power adapter into the DC input port on the bottom of the diffuser, then plug the adapter into a standard electrical outlet.
Video: A demonstration of how to install the support legs onto the YOUENKITY diffuser, showing the correct orientation and rotation until a click is heard.
Image: The YOUENKITY 500ML Large Essential Oil Diffuser showing its water capacity and mist timer options (1H, 3H, 6H, ON).
4. Иштөө нускамалары
Your diffuser can be operated using the buttons on the front panel or the included remote control.
Алыстан башкарууну колдонуу:
Image: A woman relaxing on a couch with the YOUENKITY 500ML Large Essential Oil Diffuser and its remote control on a side table, highlighting ease of use.
- КҮЙГҮЗҮҮ/ӨЧҮРҮҮ: Press to turn the diffuser on or off.
- Жарык: Press to cycle through 7 LED colors, set a fixed color, or turn the light off.
- Mist (Continuous/Intermittent): Press to select continuous mist or intermittent mist.
- Убакыт: Set the operating time to 1 hour, 3 hours, or 6 hours. The diffuser will automatically shut off after the selected time.
- Big/Small: Adjust the mist output intensity (heavy mist or light mist).
Using the Front Panel Buttons:
- ЖАРЫК баскычы: Short press to change the light color. Long press to turn off the light.
- TUMAN баскычы: Short press to cycle through timer settings (1H, 3H, 6H, ON). Long press to adjust mist intensity (heavy/light).
Image: The YOUENKITY 500ML Large Essential Oil Diffuser displaying its 7 changing mood lights, highlighting the aesthetic features.
Video: A demonstration of the YOUENKITY 500ML Diffuser's night light show, showcasing the various color options and their transitions.
5. Техникалык тейлөө
Үзгүлтүксүз тазалоо оптималдуу иштешин камсыз кылат жана диффузоруңуздун иштөө мөөнөтүн узартат.
Тазалоо көрсөтмөлөрү:
- Ажыратыңыз: Диффузорду тазалоодон мурун ар дайым розеткадан сууруп алыңыз.
- Бош суу: Танктан калган сууну бошотуңуз.
- Өчүрүү: Use a soft cloth or sponge with a small amount of mild detergent to wipe the inside of the water tank and the ultrasonic plate. Avoid harsh chemicals or abrasive cleaners.
- Чайкоо: Rinse the tank thoroughly with clean water, being careful not to get water into the air outlet.
- Кургак: Wipe all parts dry with a clean cloth.
- Weekly Quick Rinse: For regular maintenance, a weekly quick rinse with water is recommended.
Image: A hand cleaning the interior of the YOUENKITY diffuser with a cloth, illustrating the easy top-fill and weekly quick rinse feature for maintenance.
6. Кыйынчылыктарды
| Көйгөй | Мүмкүн себеп | Чечим |
|---|---|---|
| Туман жок же аз туман чыгаруу | Insufficient water; water level too high; ultrasonic plate dirty; air outlet blocked. | Add water to appropriate level; ensure water is below MAX line; clean ultrasonic plate; ensure air outlet is clear. |
| Diffuser turns off unexpectedly | Water tank empty (auto-off activated); timer setting reached. | резервуарды кайра толтуруу; таймер жөндөөлөрүн текшерүү. |
| Жарык жок | Light function turned off; power issue. | Press the Light button on the diffuser or remote to turn on; ensure power is connected. |
| Пульт иштебей жатат | Battery depleted; remote not aimed correctly. | Replace remote battery; ensure clear line of sight to diffuser sensor. |
7. Техникалык шарттар
- Бренд: YOUENKITY
- Модель аты: XXJ01
- Сыйымдуулугу: 500 миллилитр
- Иштөө убактысы: 20 саатка чейин
- Камтуу аймагы: 480 чарчы футка чейин
- Материал: Polypropylene (PP), BPA Free
- Кубат булагы: Зымдуу электр (12 ватт)
- Өзгөчөлүктөр: Automatic Shut-Off, Cool Mist, Long Lasting Aroma, Silent Operation (25dB), Timer Setting, 7 Color LED Lights
- Продукциянын өлчөмдөрү: 8.26"L x 7"W x 7"H
- Элемент Салмагы: 1.49 фунт
Image: The YOUENKITY 500ML Large Essential Oil Diffuser with dimensions of 4 inches height and 6.8 inches width, highlighting its compact size and large capacity.
8. Коопсуздук маалыматы
- Суюлтулган эфир майлары менен түздөн-түз териге тийбеңиз.
- Балдар жана үй жаныбарлары жетпеген жерде сактаңыз.
- Колдонуу учурунда туура желдетүүнү камсыз кылыңыз.
- Always follow essential oil safety guidelines.
- The diffuser features an automatic shut-off function when the water runs dry or if it overheats, ensuring safety for babies and pets.
- Do not place the diffuser on uneven surfaces.
- Аспапты сууга же башка суюктуктарга батырбаңыз.
Image: The YOUENKITY 500ML Large Essential Oil Diffuser highlighting its safety features such as overheating protection, BPA-free material, and waterless auto-off, shown near a baby in a stroller.
Image: The YOUENKITY 500ML Large Essential Oil Diffuser illustrating its automatic shut-off feature to prevent overheating and when water runs out, depicted with people relaxing during day and night.
9. Кепилдик жана колдоо
For warranty information or product support, please refer to the contact details provided on the product packaging or visit the official YOUENKITY webсайт. Бардык кепилдик дооматтар үчүн сатып алуу дүмүрчөгүңүздү сактаңыз.
