XTRONS 12.3 Inch Android 13 Car Stereo Instruction Manual

Продукт бүттүview

The XTRONS 12.3 Inch Android 13 Car Stereo is designed for Left Hand Drive Audi Q5 models from 2009-2017, specifically compatible with Audi Concert or Audi Symphony radio systems. This unit features an Octa-core processor with 4GB DDR4 RAM and 64GB Solid State ROM, running on the latest Android 13 operating system for stable and responsive performance. It boasts a 12.3-inch high-fidelity IPS touch screen with a 24:9 aspect ratio, offering wide viewing angles and detailed visuals. Key features include Global 4G LTE connectivity (Micro-SIM required, data only), built-in wireless CarPlay and wireless/wired Android Auto, Bluetooth 5.0 for stable connections, dual Wi-Fi band support (2.4GHz/5GHz), and Picture-in-Picture (PIP) functionality. The system retains original vehicle functions such as the amplifier system, radio, CD player, Bluetooth, backup camera display, and steering wheel controls.

Image: XTRONS 12.3 Inch Android 13 Car Stereo main unit, showcasing the large display and key features like 4GB RAM, 64GB ROM, Android 13, Octa Core, and 4G LTE.

Image: Comparison of 12.3-inch display size versus 10.25-inch, highlighting multi-task display, Picture-in-Picture, IPS Touch Screen, and built-in dual USB input.

Image: Visual representation of retained original car functions including amplifier system, original radio, original CD player, Bluetooth, backup camera display, and steering wheel control.

Кутуда эмне бар

• 1 × ISO зымдарынын шнуру
• 1 × LVDS Cable
• 1 × Пинцет
• 1 × 4G антеннасы
• 1 × Аудио кабель
• 1 × AMI Cable
• 1 × Mini Speaker
• 1 × GPS антеннасы
• 1 × Колдонуучунун колдонмосу
• 1 × Installation Instruction
• 1 × Mini Microphone
• 1 × Installation Frame
• 1 × Fix Mount
• 8 × Бурама

Техникалык шарттар

• Дисплей өлчөмү: 12.3 дюйм
• Модель аты: QLA22UCA12Q5L
• Операция системасы: Android 13
• Процессор: Окта ядролуу
• RAM: 4 ГБ DDR4
• ROM: 64 ГБ катуу абалдагы эс тутум
• Экран түрү: IPS сенсордук экраны
• Байланыш: Bluetooth 5.0, USB, Wi-Fi (2.4GHz/5GHz), Global 4G LTE
• Өзгөчөлүктөр: Wireless CarPlay, Wireless/Wired Android Auto, Picture-in-Picture, G52 GPU (2K video up to 60fps)
• Унаа тейлөө түрү: Car (Audi Q5 2009-2017, Left Hand Drive)
• Аудио чыгаруу режими: Динамик, стерео
• Монтаж түрү: Куралдар тактасы
• Кепилдик: 1 жыл

Орнотуу жана орнотуу

This section provides guidance for installing your XTRONS 12.3 Inch Android 13 Car Stereo. Professional installation is recommended.

Image: Illustrates the applicable Audi Q5 models (2009-2017) and compatible radio systems (Audi Concert or Audi Symphony) with before and after installation views.

Image: Detailed diagram of the wiring harness, labeling each port and cable for correct connection during installation.

Installation Video Guides

Иштөө нускамалары

Learn how to use the various features of your XTRONS car stereo.

Image: Shows how to display and control your smartphone wirelessly using Wireless CarPlay, Wireless/Cable Android Auto, and Screen Mirroring features.

Image: Details the three options for internet access: LTE Cat 7 (up to 300Mbps) via Micro-SIM, 5GHz Wi-Fi, and 2.4GHz Wi-Fi, along with mobile network sharing via USB tethering.

Operating Video Guides

Проблемаларды чечүү

Бул бөлүмдө унааңыздын стереосу менен кездешиши мүмкүн болгон жалпы көйгөйлөр каралат.

Жалпы маселелер жана чечимдер

• Үн жок: Ensure all audio cables are securely connected. Check the AUX input settings on your original car system.
• Original Car Information Not Displayed: Verify that the original CD player host is correctly plugged in and installed tightly.
• Туташуу маселелери: Check Wi-Fi and Bluetooth settings on both the stereo and your mobile device. Ensure 4G SIM card is correctly inserted and has data.

Troubleshooting Video Guides

Кепилдик жана колдоо

The XTRONS 12.3 Inch Android 13 Car Stereo comes with a 1 жылдык кепилдик. For technical support or warranty claims, please contact XTRONS customer service through your purchase platform or visit the official XTRONS webсайт.
