LVWIT LED оюкчасына орнотулган жарыктандыруу 4 дюймдук 5CCT ылдыйкы жарык берүүчү колдонмо

Introduction

Thank you for choosing LVWIT LED Recessed Lighting. This manual provides detailed instructions for the safe installation, operation, and maintenance of your 4-inch 5CCT dimmable LED downlights. Please read this manual thoroughly before installation and retain it for future reference.

Сүрөт: бүттүview of the LVWIT 4-inch LED Recessed Downlight and its components, including the light fixture and external junction box.

Коопсуздук маалыматы

Өрт, электр шок же адамдардын жаракат алуу коркунучун азайтуу үчүн, төмөнкү коопсуздук чараларын сактаңыз:

• Always turn off the power at the circuit breaker before installing, servicing, or cleaning the fixture.
• Орнотуу процессине ишенбесеңиз, квалификациялуу электрикке кайрылыңыз.
• Бардык электр байланыштары жергиликтүү коддорго жана эрежелерге ылайык жасалганын текшериңиз.
• Do not modify the fixture or use it for purposes other than its intended use.
• Бул продукт ички колдонуу үчүн гана иштелип чыккан.
• The fixture is IC rated, suitable for direct contact with insulation.

Пакеттин мазмуну

Орнотууну баштоодон мурун бардык компоненттер бар экендигин текшериңиз:

• LVWIT 4-inch LED Recessed Downlight(s)
• External Junction Box(es)
• 1:1 тешик шаблону
• Instruction Manual

Техникалык шарттар

Detailed technical specifications for the LVWIT 4-inch LED Recessed Downlight:

Image: Detailed dimensions of the 4-inch LED recessed light and its junction box, including a 120-degree beam angle and ultra-thin metal shell.

Image: Lighting Facts label indicating 800 lumens, 9 watts, 5CCT options, and an estimated yearly energy cost of $1.08.

Орнотуу боюнча колдонмо

Баштоодон мурун

• Электр өчүргүчтө кубат өчүрүлгөнүн текшериңиз.
• Verify that the ceiling space is at least 2 inches deep for proper installation.
• Use the provided 1:1 hole template to mark the cutout location accurately.

Кадам-кадам орнотуу

1. Cut a Hole: Using the provided template, cut a 4.1-inch (105mm) diameter hole in the ceiling.
2. Электр байланыштарын жасоо: Open the junction box cover. Connect the household wiring (live, neutral, ground) to the corresponding wires inside the junction box using appropriate connectors. Ensure secure connections.
3. Connect Light Panel: Connect the cable from the LED light panel to the cable from the junction box. Ensure the connection is firm.
4. Түс температурасын тандоо (CCT): Before mounting, locate the 5CCT switch on the side of the junction box. Select your desired color temperature (2700K, 3000K, 3500K, 4000K, or 5000K).
5. Mount Light: Push the spring clips on the LED light panel upwards and insert the fixture into the cutout hole. Release the clips to secure the light firmly against the ceiling.

Image: Visual guide demonstrating the quick installation process: 1. Cutting a hole, 2. Making power connections, 3. Connecting the J-box to the light module, 4. Switching CCT, 5. Fixing the light with spring clips.

Image: Illustration of the recessed light's stable spring clips and its compatibility with various ceiling types, including double drywall (0.75"), single drywall (0.37"), and soffit (0.12").

Иштөө нускамалары

Түс температурасын тандоо (5CCT)

Your LVWIT LED recessed light features 5 selectable color temperatures. Before installation, use the switch on the side of the junction box to choose your preferred CCT:

• 2700K (жылуу ак): Ideal for bedrooms, creating a cozy atmosphere.
• 3000K (Жумшак ак): Suitable for studies or areas requiring a slightly brighter, yet warm light.
• 3500K (нейтралдуу ак): Good for bathrooms, providing a balanced light.
• 4000K (муздак ак): Recommended for living rooms, offering a natural and vibrant light.
• 5000K (Күндүзгү): Best for kitchens or dining rooms, providing bright, clear illumination.

Сүрөт: Мисamples of 5CCT settings in various rooms: 2700K for bedroom, 3000K for study, 3500K for bathroom, 4000K for living room, and 5000K for kitchen, with a visual of the CCT selection switch.

Караңгылоо функциясы

These LED downlights are dimmable from 5% to 100% brightness. For optimal performance, use with compatible LED dimmers. Refer to the product specifications or consult a qualified electrician for dimmer compatibility.

Image: Illustration of the smooth dimming capability from 5% to 100% and a list of compatible Lutron and Leviton dimmer models.

Кароо жана тейлөө

To ensure the longevity and optimal performance of your LVWIT LED recessed lights, follow these simple maintenance guidelines:

• Тазалоо: Тазалоодон мурун электр кубаты өчүрүлгөнүн текшериңиз. Аппаратты жумшак, кургак же бир аз менен сүртүңүз damp Катуу химиялык заттарды же абразивдүү тазалоочу каражаттарды колдонбоңуз, анткени алар каптоого же электрдик компоненттерге зыян келтириши мүмкүн.
• Текшерүү: Periodically check for any loose connections or visible damage. If any issues are found, turn off the power and consult a qualified electrician.
• Лампаны алмаштыруу: These LED fixtures are integrated units and do not require bulb replacement. The LEDs are designed for a long lifespan.

Проблемаларды чечүү

If you encounter any issues with your LVWIT LED recessed lighting, refer to the following table for common problems and solutions:

Кепилдик жана Кардарларды колдоо

LVWIT LED recessed lighting products are designed for durability and come with a 3-YEAR warranty. Бул кепилдик нормалдуу колдонуудагы материалдардагы жана жасалгадагы кемчиликтерди камтыйт.

If you have any questions, require technical assistance, or need to make a warranty claim, please do not hesitate to contact our customer service team. We are committed to providing prompt support and aim to respond within 24 hours.

For further assistance, please visit the LVWIT Store on Amazon or refer to your purchase documentation for contact details.
