Introduction
This manual provides detailed instructions for the Ulefone Armor Mini 20T Pro 5G, a compact and rugged smartphone designed for demanding environments. It features integrated FLIR thermal imaging, 5G connectivity, and a durable build. Please read this manual carefully to ensure proper use and optimal performance of your device.
Алдыңкы жана арткы view of the Ulefone Armor Mini 20T Pro 5G smartphone, showcasing its rugged design and the thermal imaging display on the screen.
Жайгашуу
Пакеттин мазмуну
Пакетиңизде төмөнкү заттар бар экенин текшериңиз:
- 1 x Ulefone Armor Mini 20T Pro Rugged Smartphone
- 1 х заряддагыч
- 1 x USB Type-C кабели
- 1 x Tempered Glass Screen Protector Film
- 1 х SIM ийнеси
SIM картаны жана сактагычты орнотуу
The Armor Mini 20T Pro supports dual 5G SIM cards and expandable storage up to 2TB via a microSD card (sold separately).
- Аппараттын капталындагы SIM карта салгычын табыңыз.
- Insert the SIM needle into the small hole next to the tray to eject it.
- Place your Nano-SIM cards and/or microSD card into the designated slots. Ensure correct orientation.
- Табаны телефондун ичине кылдаттык менен кайра кыстарыңыз.
Side view of the Ulefone Armor Mini 20T Pro, indicating the location of the SIM card tray and physical buttons.
Күйгүзүү/өчүрүү
To power on the device, press and hold the Power button located on the side until the Ulefone logo appears. To power off, press and hold the Power button, then select "Power off" from the options.
Баштапкы конфигурация
Upon first power-on, follow the on-screen prompts to set up your Android 14 operating system, including language, Wi-Fi connection, Google account, and security settings.
Түзмөгүңүздү иштетүү
Негизги навигация
The Ulefone Armor Mini 20T Pro features a 4.7-inch HD+ touchscreen display. Navigate by tapping, swiping, and pinching gestures. Physical buttons include Power, Volume Up/Down, and a customizable side key.
A hand holding the compact Ulefone Armor Mini 20T Pro, demonstrating its suitability for single-handed operation.
Дисплей өзгөчөлүктөрү
The 4.7-inch HD+ display offers vibrant clarity and smooth motion with a resolution of 720 x 1600 pixels, 373 PPI, and a maximum brightness of 700 nits for excellent outdoor visibility.
A visual representation of the 4.7-inch HD+ display, detailing its 720x1600 resolution, 373 PPI, and 700 nits maximum brightness.
Камера функциялары
The device is equipped with a 50MP main camera (ISOCELL GN1 sensor) and supports underwater photography. The front camera is 32MP.
To access the camera, tap the Camera icon on your home screen or app drawer. Select modes such as Photo, Video, Portrait, and Underwater. Adjust settings like resolution, flash, and filters as needed.
Thermal Imaging with FLIR Lepton 3.5
The integrated FLIR Lepton 3.5 thermal camera allows you to visualize heat signatures. Access this feature via the MyFLIR Pro application.
- Температураны өлчөө диапазону: -10°Cден 450°Cге чейин.
- VividIR™ Technology: Enhances thermal image clarity.
- MSX® Intensity: Blends visible light details with thermal images for better context.
- Thermal Locking: Locks the temperature range for specific analysis.
- Customizable Circular Area: Monitor temperature within a defined circular region.
- Horizontal/Vertical Line: Measure average temperature along a line.
Screenshots illustrating various features of the MyFLIR Pro application, including VividIR activation, temperature alerts, MSX intensity adjustment, thermal locking, and customizable measurement areas.
A visual representation of the FLIR Lepton 3.5 thermal camera in action, showing its ability to detect heat signatures and its integration into the smartphone.
Байланыш
Сиздин аппаратыңыз бир катар байланыш параметрлерин колдойт:
- 5G тармагы: High-speed mobile data for streaming and downloads.
- Wi-Fi: Connect to wireless networks. The device can also act as a 5G mobile hotspot.
- Bluetooth: Pair with wireless accessories.
- GPS: For navigation and location services, supporting 5 navigation systems.
- NFC: For contactless payments (Google Pay supported) and data transfer.
- IR эмитенти: Control compatible infrared devices.
An illustration demonstrating the Ulefone Armor Mini 20T Pro's 5G high-speed network access and its capability to function as a mobile 5G Wi-Fi hotspot.
Өзгөчөлүктөр
- Versatile LED Light: A powerful LED light with 130 LEDs and up to 500 lumens, offering various modes for camping, hiking, cycling, and emergency lighting.
- Ыңгайлаштырылган ачкыч: A programmable physical button for quick access to frequently used functions or apps.
- Кол кап режими: Enhances touchscreen sensitivity for use with gloves.
- Emergency Warning Light: Utilizes the versatile LED light for signaling in emergency situations.
- Outdoor Toolbox: A suite of pre-installed tools useful for outdoor activities.
- 3.5 мм гарнитура уясы: For wired audio connections.
- FM радиосу: Listen to FM radio without needing headphones as an antenna.
A person using the Ulefone Armor Mini 20T Pro's versatile LED light in a dark outdoor setting, highlighting its brightness and utility for various activities.
Батарея башкаруу
The device is powered by a 6200mAh battery, offering extended usage times. It supports 33W fast charging and 15W wireless charging. Reverse charging is also supported, allowing you to charge other devices.
A graphic emphasizing the 6200mAh battery capacity and its 14-day light use autonomy, with details on standby, call, and video playback durations.
Техникалык тейлөө жана бышыктык
Катуу дизайн
The Ulefone Armor Mini 20T Pro is built to withstand harsh conditions:
- IP68/IP69K рейтинги: Dustproof and waterproof, submersible up to 1.5 meters for 30 minutes.
- MIL-STD-810H сертификатына ээ: Military-grade durability against drops (up to 1.2 meters) and extreme temperatures.
- Corning® Gorilla® Glass Victus: Enhanced scratch and drop resistance for the display.
- Extreme Temperature Operation: Functions reliably in temperatures as low as -30°C.
Сүрөт шоуcasing the Corning Gorilla Glass Victus for enhanced durability and the phone's ability to operate in extreme cold (-30°C) and heat (55°C).
Тазалоо жана кам көрүү
Түзмөгүңүздү жакшы абалда кармоо үчүн, аны жумшак, нымдуу чүпүрөк менен сүртүңүзamp cloth. Avoid harsh chemicals or abrasive materials. Ensure all port covers are securely closed to maintain water and dust resistance.
Проблемаларды чечүү
If you encounter issues with your Ulefone Armor Mini 20T Pro 5G, try the following common solutions:
- Түзмөк күйбөй жатат: Ensure the battery is charged. Connect to the charger for at least 15 minutes before attempting to power on again.
- Начар тармак сигналы: Check your SIM card installation. Move to an area with better network coverage. Restart the device.
- Колдонмолор бузулуп же катып калууда: Close background applications. Clear the cache of the problematic app. Restart the device.
- Сенсордук экран жооп бербейт: Restart the device. If the issue persists, perform a factory reset (backup your data first).
- Thermal camera issues: Ensure the MyFLIR Pro app is updated. Check for any physical obstructions on the thermal camera lens.
For more complex issues, refer to the official Ulefone support webсайтка же кардарларды тейлөөгө кайрылыңыз.
Техникалык мүнөздөмөлөр
| Өзгөчөлүк | Деталь |
|---|---|
| Бренд | Ulefone |
| Модель номери | ARMOR 20T PRO |
| Операция системасы | Android 14 |
| Дисплей | 4.7-inch HD+ (720 x 1600 resolution, 373 PPI, 700 nits max brightness) |
| Процессор | MediaTek Dimensity 6300 5G SoC (up to 2.4 GHz) |
| RAM | Up to 16GB (8GB physical + 8GB virtual) LPDDR4X |
| Ички сактагыч | 256 ГБ UFS2.2 |
| Кеңейтүүчү сактагыч | MicroSD card up to 2TB |
| Башкы камера | 50MP ISOCELL GN1 (1/1.31" sensor, 1.2µm pixel size, f/1.95 aperture) |
| Алдыңкы камера | 32MP |
| Жылуулук камерасы | FLIR Lepton 3.5 (160 x 120 resolution, -10°C to 450°C range) |
| Батарея | 6200 мАч литий-полимер |
| Заряддоо | 33W Fast Charging, 15W Wireless Charging, Reverse Charging |
| Туруктуу | IP68/IP69K, MIL-STD-810H, Corning Gorilla Glass Victus |
| Байланыш | 5G, Wi-Fi, Bluetooth, GPS, NFC, IR Emitter, USB Type-C |
| Башка өзгөчөлүктөр | Versatile LED Light (500 lumens), Custom Key, Glove Mode, Emergency Warning Light, Outdoor Toolbox, 3.5mm Headphone Jack, FM Radio |
An infographic summarizing the key technical specifications and features of the Ulefone Armor Mini 20T Pro 5G smartphone, including its thermal camera, battery, display, and ruggedness.
A detailed diagram illustrating the memory architecture of the Ulefone Armor Mini 20T Pro, showing 8GB physical RAM, 8GB virtual RAM, 256GB ROM, and support for up to 2TB SD card expansion.
Кепилдик жана колдоо
Ulefone provides a standard manufacturer's warranty for the Armor Mini 20T Pro 5G. Please refer to the warranty card included in your package or visit the official Ulefone webдеталдуу кепилдик шарттары жана шарттары үчүн сайт.
For technical support, troubleshooting assistance, or service inquiries, please contact Ulefone customer support through their official channels.
