1. Киришүү
Thank you for choosing the Hunter 52-inch White Indoor Ceiling Fan. This fan is designed to provide optimal air circulation and lighting for medium to large rooms, including bedrooms, dens, dining rooms, kitchens, and offices. Featuring energy-efficient, dimmable LED bulbs and reversible blades, this fan offers both functionality and modern design. The included handheld remote control ensures convenient operation of fan speeds and lighting.
Image: The Hunter 52-inch White Indoor Ceiling Fan, showcasing its sleek design with five blades and an integrated light kit. Labels point to the reversible motor, reversible blades, and long-lasting LED bulbs.
2. Коопсуздук маалыматы
WARNING: To reduce the risk of fire, electric shock, or personal injury, always follow these instructions:
- Орнотууну баштоодон мурун бардык нускамаларды кылдат окуп чыгыңыз.
- Орнотуу жери структуралык жактан бекем экенин жана желдеткичтин салмагын көтөрө алаарын текшериңиз.
- Turn off power at the circuit breaker before wiring.
- Зымдарды орнотуу процедуралары боюнча күмөн санасаңыз, квалификациялуу электрикке кайрылыңыз.
- Вентиляторду бычактары бузулган абалда иштетпеңиз.
- Keep hands and objects clear of rotating blades.
3. Пакеттин мазмуну
Орнотууну баштоодон мурун бардык компоненттер бар экендигин текшериңиз:
- Шыптын желдеткичинин мотору
- 5 Fan Blades (Light Oak/Matte White reversible)
- Интеграцияланган LED жарык комплекти
- Handheld Remote Control (with batteries)
- 4-inch Downrod for Standard Profile Монтаждоо
- Mounting Hardware and Wiring Connectors
Сүрөт: деталдуу view of the Hunter 52-inch White Indoor Ceiling Fan, highlighting its key features: reversible motor, reversible blades, and long-lasting LED bulbs. This image helps identify the main components.
4. Орнотуу жана орнотуу
The Hunter 52-inch Ceiling Fan is designed for easy installation with reduced hardware and pre-installed pieces. Follow the detailed instructions provided in the included manual for a smooth setup. Ensure power is off at the circuit breaker before starting.
4.1 Желдеткичти орнотуу
This fan supports standard profile mounting with the included 4-inch downrod. For rooms with low ceilings, the low-profile design ensures ample clearance. If you have existing wiring, installation will be straightforward.
4.2 Бычактарды бекитүү
The fan features 5 reversible blades with Light Oak on one side and Matte White on the other. Choose the finish that best suits your room's aesthetic. Securely attach the blades to the motor housing as per the manual's diagrams.
Image: Close-up of the reversible fan blades, showing both the Light Oak and Matte White finishes. This illustrates the customization option for matching room decor.
4.3 Wiring the Light Kit
Connect the integrated LED light kit according to the wiring instructions. The LED bulbs are energy-efficient and dimmable, providing versatile lighting options.
Видео: Сатуучу тарабынан берилген жоопview of the Hunter 52-inch fan, demonstrating its features and ease of installation. This video offers a visual guide to the product's functionality.
5. Иштөө нускамалары
Your Hunter ceiling fan comes with a convenient handheld remote control for easy operation.
5.1 желдеткич ылдамдыгын көзөмөлдөө
The fan features a three-speed WhisperWind motor for powerful yet quiet air movement. Use the remote to adjust the fan speed to your desired level.
5.2 Light Control and Dimming
The integrated LED light kit can be turned on/off and dimmed using the remote. Hold down the light button to adjust brightness and create the perfect ambiance.
5.3 Reversible Motor (Summer/Winter Mode)
The fan's reversible motor allows for year-round comfort. In summer, set the blades to spin counter-clockwise to create a cooling downdraft. In winter, reverse the motor to spin clockwise on low speed, creating an updraft that circulates warm air trapped near the ceiling.
Image: Diagram illustrating the reversible multi-speed motor for Summer Mode (counter-clockwise downdraft) and Winter Mode (clockwise updraft), enhancing year-round comfort.
Image: The handheld remote control, detailing buttons for light dimming, changing fan speed, and changing fan direction. It also indicates that batteries are included.
Видео: Сатуучу тарабынан берилген жоопview highlighting the Hunter Dempsey Low Profile Fan, including its quiet operation and remote control features. This video demonstrates the fan's performance and user convenience.
6. Техникалык тейлөө
Үзгүлтүксүз тейлөө сиздин шыптын желдеткичиңиздин оптималдуу иштешин жана узак иштөөсүн камсыз кылат.
- Тазалоо: жумшак колдонуу, damp Желдеткичтин калактарын жана мотордун корпусун тазалоо үчүн чүпүрөк колдонуңуз. Абразивдүү тазалоочу каражаттарды же эриткичтерди колдонбоңуз.
- Бычак текшерүү: Мезгил-мезгили менен бычактын бардык бурамалар бекем экендигин текшерип туруңуз. Бошогон бурамалар солкулдап, ызы-чуу жаратышы мүмкүн.
- Light Kit: The LED bulbs are long-lasting and generally do not require replacement. If issues arise, consult the troubleshooting section.
7. Кыйынчылыктарды
If you experience issues with your Hunter ceiling fan, refer to the following common problems and solutions:
| Көйгөй | Мүмкүн себеп | Чечим |
|---|---|---|
| Күйөрман иштебейт | No power to the fan; loose wiring; remote control issue. | Check circuit breaker; ensure all wiring connections are secure; replace remote batteries. |
| Күйөрман солкулдайт | бош бурамалар; тең салмактуу эмес бычактар; туура эмес орнотуу. | Tighten all blade screws; use balancing kit (not included) if needed; re-check mounting. |
| Жарык иштебейт | Loose wiring; remote control issue; LED driver failure. | Check wiring connections; replace remote batteries; contact support if LED driver is suspected. |
| Желдетүүчү ызы-чуу | Loose screws; motor issue; blades hitting an obstruction. | Tighten all screws; ensure no obstructions; contact support if motor noise persists. |
8. Техникалык шарттар
- Бренд: Hunter
- Модель аты: CCC5C25C91
- Продукциянын өлчөмдөрү: 52"D x 52"W x 14.75"H
- Түсү: Matte White
- Бычактардын саны: 5 (Reversible: Light Oak/Matte White)
- Мотор түрү: AC WhisperWind Motor (3-speed, Reversible)
- Light Kit: Integrated, Dimmable LED
- Башкаруу ыкмасы: Кол менен башкарылуучу
- Монтаж түрү: Downrod Mount (4-inch downrod included)
- Аба агымынын кубаттуулугу: Мүнөтүнө 2901 куб фут
- Ватtage: 9 ватт
- Тtage: 120 вольт
- Элемент Салмагы: 19.6 фунт
- Ички/тышкы колдонуу: Indoor
- Техникалык мүнөздөмөлөрү: ETL
Image: A diagram illustrating the dimensions of the Hunter 52-inch ceiling fan for both standard (4-inch downrod) and angled mounting options. This helps users determine suitability for their space.
9. Кепилдик жана колдоо
For warranty information and customer support, please refer to the documentation included with your product or visit the official Hunter Fan website. Additional protection plans may be available for purchase, offering extended coverage for your product.
For immediate assistance, you may also contact the seller directly through your purchase platform.
