1. Киришүү
Thank you for choosing the Panda Portable Spin Dryer. This manual provides essential information for the safe and efficient operation, maintenance, and troubleshooting of your new appliance. Please read these instructions thoroughly before first use and retain them for future reference.
The Panda Portable Spin Dryer is designed to quickly remove excess water from laundered items, significantly reducing drying time. Its compact design and durable stainless steel drum make it suitable for various living spaces, including apartments, dorms, RVs, and boats.
2. Маанилүү коопсуздук нускамалары
- Шайманды колдонуудан мурун бардык нускамаларды окуп чыгыңыз.
- кубат менен камсыз кылуу Voltagшайманда көрсөтүлгөн e (110V).
- Do not operate the spin dryer with a damaged power cord or plug.
- Always place the spin dryer on a firm, level surface to prevent excessive vibration and movement during operation.
- Do not overload the spin dryer. Distribute items evenly inside the drum to maintain balance.
- Keep hands and foreign objects out of the drum while the appliance is operating.
- Ensure the lid is securely closed and the safety lock engaged before starting the spin cycle.
- Never attempt to open the lid or stop the drum manually while it is spinning. Wait for the drum to come to a complete stop.
- Шайманды колдонбогондо же тазалоодон мурун электр розеткасынан сууруп алыңыз.
- Бул шайман тиричиликте гана колдонууга арналган.
3. Продукт бүтүп калдыview жана компоненттер
Familiarize yourself with the main parts of your Panda Portable Spin Dryer.
3.1-сүрөт: Фронт view of the Panda Portable Spin Dryer in silver finish. This image displays the overall cylindrical design, the Panda logo, and the drain spout located near the bottom.
Камтылган компоненттер:
- Spin Disc
- Электр кабели
Негизги бөлүктөр:
- Дат баспас болоттон жасалган барабан: The inner chamber where clothes are placed for spinning.
- Капкак: Covers the drum. Must be closed during operation.
- Коопсуздук кулпу: A mechanism that secures the lid and prevents operation when open.
- Power Handle/Switch: Used to initiate and stop the spin cycle.
- Drain Spout: Outlet for expelled water.
3.2-сүрөт: Жакын план view of the safety lock button located on the top rim of the spin dryer. An arrow sticker indicates to press the button to open the lid.
3.3-сүрөт: View into the open lid of the spin dryer, showing the transparent inner lid and the top of the stainless steel drum.
3.4-сүрөт: Деталдаштырылган view of the perforated stainless steel drum interior, designed for efficient water extraction.
3.5-сүрөт: Close-up of the black drain spout located on the side of the spin dryer, with a blue sticker indicating 'DRAIN SPOUT'.
3.6-сүрөт: The power cord with a standard two-prong plug, used to connect the spin dryer to an electrical outlet.
4. Орнотуу
- Пакеттен чыгаруу: Carefully remove the spin dryer from its packaging. Inspect for any shipping damage. Remove all packing materials, including any foam inserts from inside the drum.
- Жайгашкан жери: Place the spin dryer on a stable, flat, and level surface. Ensure there is sufficient space around the unit for air circulation and access.
- Дренаж: Position a bucket or suitable container directly under the drain spout to collect the expelled water. The spin dryer uses gravity drainage and does not require a direct drain connection.
- Кубат туташуу: Кубат шнурын жерге туташтырылган 110 В электр розеткасына сайыңыз.
4.1-сүрөт: The Panda Spin Dryer positioned on a mat in a kitchen, demonstrating its compact size and ease of placement in various household environments.
5. Операция
- Буюмдарды даярдоо: Ensure items are thoroughly washed and rinsed before placing them in the spin dryer.
- Элементтерди жүктөө: Open the lid by pressing the safety lock button. Place wet items loosely and evenly around the drum. Avoid overloading, as this can cause imbalance and reduce efficiency. The maximum capacity is 22 lbs.
- Insert Spin Disc: Place the provided spin disc on top of the loaded items inside the drum. This helps to keep items contained during the spin cycle.
5.1-сүрөт: The white perforated spin disc shown separately and then placed inside the spin dryer drum on top of laundry, illustrating its correct positioning for use.
- Жабуу: Close the lid securely until the safety lock engages. The appliance will not operate if the lid is not properly closed.
- Start Spin Cycle: Turn the power handle/switch to the 'ON' position. The drum will begin to spin. The spin dryer features a 5-minute timer and will automatically shut off after the cycle is complete.
5.2-сүрөт: A composite image showing the power handle in both 'Power Off' (horizontal) and 'Power On' (vertical) positions, indicating how to activate the spin cycle.
- Monitor Drainage: Ensure the bucket placed under the drain spout is collecting water effectively. Empty the bucket as needed.
- Unload Items: Once the spin cycle is complete and the drum has come to a full stop, open the lid and remove the spin disc and items. Items will be damp but significantly drier than after a typical wash cycle.
6. Техникалык тейлөө
Regular maintenance ensures optimal performance and longevity of your spin dryer.
- Барабанды тазалоо: After each use, wipe the interior of the stainless steel drum with a clean, damp cloth to remove any lint or residue.
- Тышкы тазалоо: Сырткы беттерин жумшак, гamp кездеме. Абразивдүү тазалагычтарды же эриткичтерди колдонбоңуз.
- Drain Spout: Periodically check the drain spout for any blockages and clear them if necessary.
- Сактагыч: When not in use, store the spin dryer in a dry, well-ventilated area. Ensure it is unplugged.
7. Кыйынчылыктарды
| Көйгөй | Мүмкүн себеп | Чечим |
|---|---|---|
| Spin dryer does not start. | Not plugged in; Lid not closed properly; Power handle not in 'ON' position. | Check power connection; Ensure lid is securely closed and safety lock engaged; Turn power handle to 'ON'. |
| Ашыкча титирөө же ызы-чуу. | Uneven load distribution; Appliance not on a level surface; Overloaded drum. | Stop the machine, redistribute items evenly; Ensure appliance is on a level surface; Reduce load size. |
| Суу агып кетпейт. | Drain spout blocked; Collection bucket full or improperly placed. | Check and clear drain spout; Empty or reposition collection bucket. |
| Items still very wet after cycle. | Overloaded drum; Items too absorbent or dense; Short spin cycle. | Reduce load size; Consider a second spin cycle for very dense items. |
8. Техникалык шарттар
| Өзгөчөлүк | Деталь |
|---|---|
| Бренд | Панда |
| Модель номери | PANSP22_01 |
| Кубаттуулугу | 22 фунт |
| Айландыруу ылдамдыгы | 3200 RPM |
| Тtage | 110V |
| Барабан материалы | Дат баспаган болот |
| Элемент Салмагы | 29 фунт |
| Пакеттин өлчөмдөрү | 28 x 15 x 15 дюйм |
| Түс | Silver |
| Камтылган компоненттер | Spin Disc, Power cord |
| Дата биринчи жеткиликтүү | 24-октябрь, 2024-жыл |
9. Кепилдик жана колдоо
This Panda Portable Spin Dryer (Model PANSP22_01) comes with a 1 жылдык Өндүрүүчүнүн Кепилдиги сатып алынган күндөн тартып. Бул кепилдик нормалдуу колдонуудагы материалдардагы жана жасалгадагы кемчиликтерди камтыйт.
For warranty claims, technical support, or any questions regarding your product, please contact Panda customer service. Refer to the contact information provided with your purchase documentation or visit the official Panda webжардам үчүн сайт.
Кепилдикти текшерүү үчүн сатып алганыңыздын далилин сактап коюңуз.
