1. Продукт бүтүп калдыview
The SHIHOT 72-inch Large Ceiling Fan is designed for both indoor and outdoor use, featuring a modern black finish and 8 reversible blades. It includes an integrated LED light with adjustable color temperature and dimming capabilities. The fan is equipped with a quiet DC motor offering 6 speed settings and a reversible function for year-round comfort. Control is convenient via the included remote or a dedicated mobile application.
Figure 1: SHIHOT 72-inch Large Ceiling Fan with remote and app interface.
2. Коопсуздук маалыматы
Please read all instructions carefully before beginning installation. Improper installation or operation can lead to electric shock, fire, or personal injury. Retain this manual for future reference.
- Орнотуудан же тейлөөдөн мурун автоматтык өчүргүчтөн электр энергиясы өчүрүлгөнүн текшериңиз.
- All electrical wiring must comply with national and local electrical codes. If unsure, consult a qualified electrician.
- Mount the fan to a ceiling outlet box marked "Acceptable for Fan Support of 35 lbs (15.9 kg) or less" and use the mounting screws provided with the outlet box.
- Орнотуу, тең салмактоо же тазалоо учурунда бычак кармагычтарды ийбеңиз.
- Avoid placing objects in the path of the rotating blades.
- Бул желдеткич г үчүн ылайыктууamp locations, such as covered patios, but not for direct exposure to water.
3. Пакеттин мазмуну
Verify all components are present and undamaged before beginning assembly. Refer to the installation video for visual identification of parts.
- Вентилятордун мотору
- Чатыр
- Horn Hood
- Кронштейн орнотуу
- Downrod (includes 8-inch and 16-inch options)
- Blades (8 pieces, reversible black/wood grain)
- LED Lampкөлөкө
- Blade Arms (4 pieces)
- Алыстан башкаруу
- Instruction Manual
- Аппараттык пакет (буроолор, шайбалар, зым гайкалар)
Figure 2: Fan dimensions and recommended room size (18FT*18FT to 25FT*25FT).
4. Орнотуу жана орнотуу
This section provides detailed steps for assembling and installing your SHIHOT ceiling fan. For a visual guide, please refer to the official installation video below.
Video 1: SHIHOT Ceiling Fan Installation Guide. This video demonstrates the complete assembly and mounting process.
Чогултуу кадамдары:
- Assemble Blade Arms: Attach the blade arms to the fan motor assembly using the provided screws. Ensure they are securely fastened.
Figure 3: Securely attach the blade arms to the motor housing.
- Бычактарды бекитүү: Select your preferred blade finish (wood grain or black). Align each blade with the pre-drilled holes on the blade arms and secure them with the designated screws.
Figure 4: Blades can be installed with either the wood grain or black side facing down.
- LED Light Kit орнотуу: Connect the LED light board to the fan motor's wiring. Carefully place the LED board into its designated slot and secure the lampкөлөкө.
Figure 5: The integrated LED light provides adjustable illumination.
- Prepare Downrod: Insert the downrod through the canopy and horn hood. Feed the motor wires through the downrod. Secure the downrod to the fan motor assembly using the provided pin and screw.
- Монтаждык кронштейнди орнотуу: Secure the mounting bracket to your ceiling outlet box. Ensure the bracket is firmly attached to a structural support capable of holding the fan's weight.
- Асма желдеткичти чогултуу: Carefully lift the fan assembly and hang it on the mounting bracket. Ensure the ball joint of the downrod is properly seated in the bracket's opening.
- Электр байланыштары: Connect the fan's electrical wires to your household wiring according to the wiring diagram in the included manual. Typically, this involves connecting live, neutral, and ground wires. Ensure all connections are secure with wire nuts.
- Коопсуз чатыр: Slide the canopy up to the ceiling and secure it to the mounting bracket with the provided screws, covering the electrical connections.
5. Иштөө нускамалары
Your SHIHOT ceiling fan can be operated using the included remote control or a compatible mobile application. The fan features 6 speed settings, a reversible function, and a dimmable LED light with adjustable color temperature.
Video 2: SHIHOT Ceiling Fan Features Overview. This video demonstrates the fan's various functions including speed, light, and reverse modes.
Алыстан башкаруу функциялары:
- Желдетүүчү ылдамдыкты көзөмөлдөө: Желдеткичтин ылдамдыгын 1ден (эң төмөнкү) 6ке (эң жогорку) чейин тууралаңыз.
- Speeds 1-2: Gentle air circulation, suitable for sleeping.
- Speeds 3-4: Natural wind, ideal for daily use.
- Speeds 5-6: Strong wind, effective for rapid cooling or exercise.
Figure 6: Six adjustable fan speeds for various comfort levels.
- Жарык күйгүзүү/өчүрүү: LED жарыгын күйгүзүңүз же өчүрүңүз.
- Түс температурасын жөндөө: Cycle through warm light (3000K), natural light (4500K), and cool white light (6000K).
Figure 7: Choose from three light color temperatures to suit your ambiance.
- Караңгылатуу функциясы: Adjust the brightness of the LED light from 0% to 100%.
- Таймерди орнотуу: Желдеткичти 1, 2, 4 же 8 сааттан кийин автоматтык түрдө өчүп тургандай кылып коюңуз.
Figure 8: The fan features a convenient timer function for up to 8 hours.
- Тескери функция: Press the 'R' key on the remote. The fan will stop completely and then automatically reverse direction.
- Summer Mode (Forward Rotation): Creates a downward airflow, providing a cooling effect.
- Winter Mode (Reverse Rotation): Creates an upward airflow, circulating warm air trapped near the ceiling.
Figure 9: Utilize the reversible function for optimal comfort in both summer and winter.
Mobile Application Control:
Download the compatible mobile application (refer to the included manual for QR code or app store details). The app allows for comprehensive control over all fan and light functions, similar to the remote control.
6. Негизги өзгөчөлүктөрү
- Тынч туруктуу кыймылдаткыч: The fan is equipped with a high-quality DC motor that ensures smooth, silent operation, providing a comfortable and peaceful environment. This motor is also energy-efficient, reducing electricity costs.
Figure 10: The efficient DC motor ensures quiet operation and energy savings.
Figure 11: Experience a quiet environment with the fan operating at approximately 30dB.
- Кайтарылуучу бычактар: The 8 fan blades feature a dual-sided design, allowing you to choose between a classic black finish or a stylish wood grain finish to match your interior decor.
Figure 12: Customize your fan's appearance with reversible blades.
- Чоң камтуу: With a 72-inch span, this fan is ideal for medium to large rooms, including living rooms, bedrooms, offices, studies, and kitchens, providing effective air circulation.
7. Техникалык тейлөө
Үзгүлтүксүз тейлөө сиздин шыптын желдеткичиңиздин оптималдуу иштешин жана узак иштөөсүн камсыз кылат.
- Тазалоо:
- Тазалоодон мурун дайыма өчүргүчтөн электр кубатын өчүрүңүз.
- жумшак колдонуу, damp Желдеткичтин калактарын жана мотордун корпусун тазалоо үчүн чүпүрөк колдонуңуз. Абразивдүү тазалоочу каражаттарды же эриткичтерди колдонбоңуз.
- For the LED lampshade, wipe gently with a dry, lint-free cloth.
- Blade балансы: If the fan wobbles, check that all blade screws are tight. Minor wobbling can often be corrected using a fan blade balancing kit (not included).
- Майлоо: Туруктуу токтун кыймылдаткычы туруктуу майланган жана кошумча майлоону талап кылбайт.
8. Кыйынчылыктарды
Оңдоо иштерин жүргүзүүдөн мурун, автоматтык өчүргүчтөн электр кубаты өчүрүлгөнүн текшериңиз.
| Көйгөй | Мүмкүн себеп | Чечим |
|---|---|---|
| Күйөрман иштебейт. | No power to the fan; loose wire connections; remote control battery low or not paired. | Check circuit breaker; verify all wire connections are secure; replace remote battery or re-pair remote. |
| Күйөрман термелет. | бош бурамалар; тең салмактуу эмес бычактар; туура эмес орнотуу. | Tighten all blade screws; use a balancing kit; ensure mounting bracket is securely installed. |
| Жарык иштебейт. | Loose wire connection to light kit; LED board failure; remote control issue. | Check light kit wiring; contact customer support if LED board is faulty; check remote battery/pairing. |
| Пульт иштебей жатат. | Low battery; interference; not paired with fan. | Replace batteries (2 x 12V included); ensure no strong interference sources; follow pairing instructions in manual. |
| Фанат үн чыгарат. | Loose screws; internal motor issue; blades hitting an obstruction. | Check all screws; ensure no obstructions; if motor noise persists, contact support. |
9. Техникалык шарттар
- Бренд: ШИХОТ
- Модель аты: 6667
- Өлчөмү: 72 дюйм
- Түсү: Кара
- Материал: Plastic, Iron
- Бычактардын саны: 8 (кайтарылуучу)
- Мотор түрү: DC Motor
- Ылдамдык жөндөөлөрү: 6
- Жарык булагы: Интегралдык LED
- Түс температурасы: 3000K (Warm), 4500K (Natural), 6000K (Cool White)
- алсыздатуу: Yes, 0-100%
- Таймер: 1Н, 2Н, 4Н, 8Н
- Башкаруу ыкмасы: Remote Control, Mobile App
- Тtage: 120 вольт
- Ватtage: 75 ватт
- Продукциянын өлчөмдөрү: 72 x 72 x 15 дюйм
- Элемент Салмагы: 24.1 фунт
- Сунушталган бөлмө көлөмү: 18FT*18FT to 25FT*25FT
- Камтылган компоненттер: Light Kit, Remote Control, 2 x 12V Batteries (for remote)
10. Кепилдик жана колдоо
SHIHOT provides a limited warranty for this product. For detailed warranty information, including coverage period and terms, please refer to the warranty card included in your product packaging or visit the official SHIHOT webсайт.
For technical support, troubleshooting assistance, or replacement parts, please contact SHIHOT customer service through the contact information provided in your product manual or via the SHIHOT Store on Amazon.
