NEWFAST AXE5400 PCIe WiFi Card User Manual

1. Киришүү

This manual provides comprehensive instructions for the installation, operation, and maintenance of your NEWFAST AXE5400 PCIe WiFi Card (NF-P395). This internal network card is designed to enhance your desktop PC's wireless capabilities, offering WiFi 6E tri-band connectivity and Bluetooth 5.3. It features the Intel AX210 chipset, supporting high-speed data transfer rates and advanced network technologies like MU-MIMO and OFDMA for an optimized wireless experience.

Сүрөт 1.1: Бүттүview of the NEWFAST AXE5400 PCIe WiFi Card's key features, including WiFi 6E, Intel AX210 chipset, Bluetooth 5.3, MU-MIMO, OFDMA, and tri-band speed capabilities.

2. Пакеттин мазмуну

Төмөндө тизмеленген нерселердин баары пакетиңизге камтылганын текшериңиз:

• 1 x NEWFAST AXE5400 PCIe WiFi Card (NF-P395)
• 1 х Колдонуучунун колдонмосу (бул документ)
• 1 x Bluetooth Cable
• 2 x 5 dBi Detachable Antennas
• 1 x Replaceable Low-Profile кашаа
• 1 x Tightening Screws

Image 2.1: The NEWFAST AXE5400 PCIe WiFi Card with its two external antennas, highlighting its WiFi 6E and Bluetooth 5.3 capabilities.

3. Системалык талаптар

• Операция системасы: Windows 10 (64-бит) же Windows 11 (64-бит). Note: The 6GHz band is only available on Windows 11 systems. Windows 10 systems will utilize the 5GHz and 2.4GHz bands.
• PCIe Slot: An available PCI Express slot (PCIe x1, x4, x8, or x16).
• Motherboard: An available F_USB header on the motherboard for Bluetooth functionality.

Image 3.1: Visual representation of the supported operating systems, Windows 10 (64-bit) and Windows 11 (64-bit).

4. Орнотуу жана орнотуу

4.1. Физикалык орнотуу

1. Power Off PC: Компьютериңизди толугу менен өчүрүп, электр кабелин розеткадан ажыратыңыз.
2. Ачык PC Case: Эне платага кирүү үчүн компьютериңиздин каптал панелин алып салыңыз.
3. PCIe уячасын табыңыз: Identify an available PCI Express slot (x1, x4, x8, or x16). Remove the corresponding metal bracket cover from the PC case.
4. WiFi картасын салыңыз: Carefully insert the NEWFAST AXE5400 PCIe WiFi Card into the chosen PCIe slot, ensuring it is firmly seated. Secure the card with a screw. If your case requires a low-profile кронштейн, картадагы стандарттуу кронштейнди берилген аз пропорционалдуу кронштейн менен алмаштырыңызfile one before installation.
5. Bluetooth кабелин туташтырыңыз: Connect one end of the included Bluetooth cable to the 9-pin F_USB header on the WiFi card and the other end to an available F_USB header on your motherboard. This connection is essential for Bluetooth functionality.
6. Антенналарды тиркөө: Эки ажыратылуучу антеннаны WiFi картасынын артындагы туташтыргычтарга бурап коюңуз. Оптималдуу сигнал кабыл алуу үчүн алардын багытын тууралаңыз.
7. Компьютердин корпусун жабуу: Reattach the side panel of your computer case and reconnect the power cable.

Image 4.1: Illustration of different PCIe slot types available on a motherboard, indicating compatibility with the WiFi card.

4.2. Драйверди орнотуу

After physical installation, you must install the necessary drivers for the WiFi card and Bluetooth module to function correctly.

1. Компьютерди күйгүзүү: Start your computer.
2. Драйверлерди жүктөп алыңыз: Visit the official NEWFAST support website or the Intel website (for AX210 chipset drivers) to download the latest drivers for your operating system (Windows 10/11).
3. Драйверлерди орнотуу: Жүктөлгөн драйверди табыңыз files and follow the on-screen instructions to complete the installation. You may need to restart your computer after installation.
4. Орнотууну текшерүү: After restarting, open Device Manager (search for it in Windows) and check under 'Network adapters' and 'Bluetooth' to ensure the Intel Wi-Fi 6E AX210 and Bluetooth 5.3 devices are listed and functioning without errors.

5. Иштөө нускамалары

5.1. Wi-Fi тармагына туташуу

1. Click the Wi-Fi icon in the system tray (bottom-right corner of your screen).
2. Жеткиликтүү Wi-Fi тармактарынын тизмеси пайда болот. Каалаган тармакты тандаңыз.
3. Click Туташуу. If prompted, enter the network security key (password).
4. Эми сиздин компьютериңиз Wi-Fi тармагына туташып турушу керек.

The NEWFAST AXE5400 supports tri-band connectivity (2.4GHz, 5GHz, and 6GHz). Your system will automatically connect to the optimal band based on network availability and configuration. Remember, the 6GHz band is exclusive to Windows 11.

5.2. Bluetooth түзмөгүн жупташтыруу

Ensure the Bluetooth cable is correctly connected to your motherboard's F_USB header for Bluetooth functionality.

1. барыңыз Орнотуулар > Bluetooth жана түзмөктөр (Windows 11) же Орнотуулар > Түзмөктөр > Bluetooth жана башка түзмөктөр (Windows 10).
2. Bluetooth күйгүзүлгөнүн текшериңиз On.
3. Click Түзмөк кошуу or Bluetooth же башка аспапты кошуңуз.
4. Тандоо Bluetooth варианттардан.
5. Bluetooth түзмөгүңүздү жупташтыруу режимине коюңуз.
6. Тизмеден түзмөгүңүздү тандап, жупташтыруу процессин аяктоо үчүн экрандагы көрсөтмөлөрдү аткарыңыз.

Image 5.1: The NEWFAST AXE5400 PCIe WiFi Card's Bluetooth 5.3 capability, illustrating its connection to multiple peripheral devices.

6. Техникалык шарттар

Image 6.1: Key features of the Intel AX210 Wi-Fi 6E chipset integrated into the card, including supported technologies and operating systems.

7. Кыйынчылыктарды

If you encounter issues with your NEWFAST AXE5400 PCIe WiFi Card, refer to the following common problems and solutions:

• Wi-Fi туташуусу жок:
  • Ensure the card is properly seated in the PCIe slot.
  • Verify that the antennas are securely attached.
  • Check Device Manager to confirm the Wi-Fi adapter is recognized and drivers are installed correctly. Reinstall drivers if necessary.
  • Windows жөндөөлөрүндө Wi-Fi иштетилгенин текшериңиз.
• Жай Wi-Fi ылдамдыгы:
  • Ensure your router supports WiFi 6E (or WiFi 6) and is configured for optimal performance.
  • Check for interference from other devices or physical obstructions.
  • Роутериңиздин микропрограммасын жаңыртыңыз.
  • Adjust antenna orientation for better signal reception.
• Bluetooth иштебей жатат:
  • Verify that the Bluetooth cable is securely connected to both the card and the motherboard's F_USB header.
  • Check Device Manager to confirm the Bluetooth adapter is recognized and drivers are installed. Reinstall drivers if necessary.
  • Windows жөндөөлөрүндө Bluetooth иштетилгенин текшериңиз.
  • Ensure your Bluetooth device is in pairing mode and within range.
• Card Not Detected by PC:
  • Power off the PC, reseat the card in the PCIe slot, and restart.
  • Мүмкүн болсо, башка PCIe уячасын колдонуп көрүңүз.
  • Ensure your motherboard BIOS/UEFI settings are configured to enable PCIe slots.

8. Техникалык тейлөө

To ensure the longevity and optimal performance of your NEWFAST AXE5400 PCIe WiFi Card, consider the following maintenance tips:

• Драйвер жаңыртуулары: Regularly check the NEWFAST or Intel website for the latest driver updates. Keeping drivers current can improve performance, stability, and security.
• Тазалык: Periodically clean the interior of your PC case to prevent dust buildup on the WiFi card's heatsink. Dust can impede heat dissipation and affect performance. Use compressed air for cleaning.
• Аба агымы: Ensure adequate airflow within your PC case to prevent overheating of components, including the WiFi card.
• Антеннанын абалы: Maintain optimal antenna positioning for the best signal strength. Avoid placing obstructions near the antennas.

9. Кепилдик жана колдоо

For warranty information and technical support, please refer to the documentation included with your purchase or visit the official NEWFAST webсайт. Колдоо ресурстарына, адатта, көп берилүүчү суроолор, драйверлерди жүктөп алуу жана кардарларды тейлөө кызматынын байланыш маалыматы кирет.

Онлайн колдоо: www.newfast.com/support (Note: This is a placeholder link. Please refer to the actual manufacturer's website for accurate support information.)
