Introduction
Welcome to the user manual for your Nolan N120-1 Modular Motorcycle Helmet. This helmet represents an innovative crossover design, featuring dual P/J homologation (full-face and jet) and a chin guard that can be reversed up to 180 degrees. The integrated Dual Action system ensures smooth and intuitive opening and closing of the chin guard. This manual provides essential information for the proper setup, operation, maintenance, and troubleshooting of your helmet to ensure safety, comfort, and longevity.
1-сүрөт: алдыңкы жагы view of the Nolan N120-1 Modular Helmet in black, with the clear visor in the closed position. This image highlights the sleek design and the integrated chin guard.
2-сүрөт: алдыңкы жагы view of the Nolan N120-1 Modular Helmet, showcasing the chin guard mechanism. The red button for the Dual Action system is visible on the side, indicating the release mechanism.
3-сүрөт: Арткы view of the Nolan N120-1 Modular Helmet, displaying the Nolan branding and the aerodynamic shape of the shell.
Жайгашуу
Таңгактан чыгаруу жана алгачкы текшерүү
Carefully remove the helmet from its packaging. Inspect the helmet for any signs of damage that may have occurred during transit. Ensure all components listed in the packaging are present and in good condition. The helmet includes the main helmet unit and its integrated features.
Шлемди орнотуу
For maximum safety and comfort, the helmet must fit snugly. Place the helmet on your head, ensuring it covers your forehead adequately. The cheek pads should fit firmly against your cheeks without causing excessive pressure or discomfort. Fasten the retention system securely under your chin, ensuring it is neither too loose nor too tight. The helmet should not move excessively when you try to rotate it from side to side or front to back.
Chin Guard Positioning
The N120-1 features a versatile reversible chin guard. For full-face (P) homologation, ensure the chin guard is securely locked in the down position. For jet (J) homologation, the chin guard can be rotated 180 degrees to rest at the rear of the helmet. Always ensure the chin guard is fully engaged and locked in its desired position before commencing your ride.
Туулганы иштетүү
Dual Action Chin Guard Opening System
The N120-1 is equipped with a Dual Action chin guard opening system. This system is designed for intuitive and secure operation, helping to prevent accidental opening. To open the chin guard:
- Locate the two release buttons positioned on the chin guard.
- Simultaneously press both buttons.
- Lift the chin guard upwards until it locks into the fully open position, or rotate it 180 degrees to the rear for jet configuration.
To close the chin guard, pull it down firmly until it clicks securely into place. Always verify the chin guard is fully locked before riding to ensure safety.
Визор операциясы
The clear main visor can be opened and closed manually. It features multiple detent positions, allowing for various levels of airflow control. To raise or lower the visor, grasp the tab located on its lower edge and move it to the desired position. The helmet is also designed to be compatible with N-Com communication systems, which are sold separately.
Техникалык тейлөө
Сырты тазалоо
Clean the helmet's exterior shell with a soft cloth and a solution of mild soap and lukewarm water. It is crucial to avoid using abrasive cleaners, solvents, or petroleum-based products, as these can severely damage the helmet's finish, paint, and structural materials. Rinse the helmet thoroughly with clean water and dry it with a soft, clean cloth.
Visor Care
Козырьканы жумшак, d менен тазалаңызamp cloth and mild soap. For stubborn dirt or dried insects, it is recommended to soak the visor in lukewarm water for a few minutes before gently wiping. Do not use abrasive materials or harsh chemical cleaners on the visor, as they can scratch or damage the surface. Allow the visor to air dry completely or gently pat dry with a clean microfiber cloth.
Ички тазалоо
The interior padding of the N120-1 is designed to be removable for cleaning. Please refer to the specific instructions provided with your helmet for the correct procedure for removal and reinstallation of the padding. Hand wash the padding with mild soap and lukewarm water. Ensure it is allowed to air dry completely before reinserting it into the helmet.
Сактагыч
Store your helmet in a cool, dry place, away from direct sunlight and extreme temperatures. Using a helmet bag is recommended to protect it from dust, scratches, and minor impacts when not in use.
Проблемаларды чечүү
| Көйгөй | Мүмкүн себеп | Чечим |
|---|---|---|
| Chin guard does not lock securely. | Obstruction in the locking mechanism; improper alignment. | Check for any debris or foreign objects in the locking mechanism. Ensure the chin guard is aligned correctly and push firmly until it clicks securely into place. |
| Visor is stiff or difficult to move. | Dirt or debris accumulated in the pivot mechanism; worn mechanism. | Clean the visor pivot points thoroughly. If the issue persists after cleaning, the mechanism may be worn, and you should contact customer support. |
| Туулга өтө кенен же өтө тар сезилет. | Incorrect helmet size for your head; interior padding not properly seated. | Ensure you have selected the correct helmet size according to Nolan's sizing guide. Check if the interior padding is correctly installed and seated within the helmet shell. |
Техникалык шарттар
- Модель аты: N120-1
- Өндүрүүчү: Нолан
- Түрү: Мотоциклдин модулдук каскасы
- Гомология: Dual P/J (Full-face and Jet)
- Материал: Поликарбонат (PC)
- Chin Guard: Reversible up to 180 degrees
- Chin Guard System: Dual Action
- Шайкештик: N-Com communication systems (sold separately)
- Түсү: Нуар (Кара)
- Болжолдуу өлчөмдөрү (L x W x Y): 40 x 40 x 40 см
- Болжолдуу салмак: 1 килограмм
Кепилдик маалымат
Nolan helmets are manufactured to high-quality standards and are designed for durability and performance. This product is covered by a manufacturer's warranty against defects in materials and workmanship. The specific terms, conditions, and duration of the warranty may vary by region and country of purchase. Please retain your original proof of purchase, such as a receipt or invoice, as it will be required for any warranty claims. For detailed warranty information applicable to your region, please refer to the official Nolan website or contact your authorized Nolan dealer.
Кардарларды колдоо
For technical assistance, inquiries regarding spare parts, or any questions concerning the proper use and care of your Nolan N120-1 helmet, please contact your authorized Nolan dealer. Alternatively, you may visit the official Nolan Helmets website for comprehensive support resources, FAQs, and contact information. When contacting support, please ensure you have your helmet model (N120-1) and purchase details readily available to facilitate a quicker resolution.
Расмий Нолан Webсайт: www.nolan-helmets.com
