TATTMUSE A281M көчмө термикалык принтер колдонуучусунун колдонмосу

1. Киришүү

Thank you for choosing the TATTMUSE A281M Portable Thermal Printer. This compact and versatile device offers a convenient, inkless printing solution for various needs, from office documents to school notes and travel essentials. This manual provides detailed instructions to help you set up, operate, and maintain your printer for optimal performance.

Figure 1.1: The TATTMUSE A281M Portable Thermal Printer offers superior portability and convenience compared to traditional printers, featuring Bluetooth connectivity, a rechargeable battery, and an inkless design.

2. Кутуда эмне бар

Төмөндө тизмеленген нерселердин баары пакетиңизге камтылганын текшериңиз:

• 1 x Portable Thermal Printer (Model A281M)
• 1 x Portable Printer Carry Case
• 1 Roll 8.5" Thermal Paper
• 1 Roll 4.33" Thermal Paper
• 1 Roll 3.14" Thermal Paper
• 1 Roll 2.08" Thermal Paper
• 1 x USB-C to USB Adapter
• 1 x USB-C кабели
• 1 x Quick Start Guide

Figure 2.1: Illustrated view of all components included with your TATTMUSE A281M Portable Thermal Printer.

3. Орнотуу колдонмосу

3.1 Принтерди заряддоо

Before first use, ensure the printer is fully charged. Connect the provided USB-C cable to the printer and a compatible USB power source (e.g., wall adapter, computer USB port). The indicator light will show charging status.

3.2 Термикалык кагазды жүктөө

The TATTMUSE A281M supports various thermal paper sizes and types. To load paper:

1. Кагаз бөлүктүн капкагын ачыңыз.
2. Insert the thermal paper roll or single sheet, ensuring the printable side (usually smoother) faces the print head.
3. Кагаз багыттоочуларды кагаздын туурасына тууралаңыз.
4. Кагаз бөлүктүн капкагын бекем жабыңыз.

Figure 3.1: The printer supports various thermal paper formats, including continuous folding, single sheets, inner rolls, and stickers, in sizes such as US Letter, A4, 4.33'', 3.14'', and 2.08''.

3.3 Connecting to a Smartphone (Bluetooth)

1. Download the official TATTMUSE printer application from your device's app store (available for Android and iOS).
2. Смартфонуңузда Bluetooth иштетилгенин текшериңиз.
3. Open the TATTMUSE app and follow the in-app instructions to connect to your printer. The printer should appear as 'A281M' or similar in the device list.
4. Once connected, you can select files or pictures within the app to print.

Figure 3.2: Simple three-step process for smartphone printing: Download the app, connect via Bluetooth within the app, and select your file басып чыгаруу.

3.4 Connecting to a PC/Laptop (USB)

1. Download the necessary printer drivers from the official webсайт: a281m.labelife.cc. Drivers are available for Windows 10/11, Linux, ChromeOS, and macOS.
2. Use the provided USB-C cable to connect the A281M printer to your computer.
3. Once the driver is installed and the printer is connected, open your document or image and select 'A281M' from the printer list in your application's print dialogue.

Figure 3.3: Connect your printer to a laptop or PC via USB after downloading the appropriate drivers from the provided webсайт.

4. Иштөө нускамалары

4.1 Негизги басып чыгаруу

After connecting your printer via Bluetooth or USB, you can initiate printing from your chosen device. Ensure your document or image is properly formatted for the thermal paper size you are using. The printer will automatically feed the paper and produce the printout.

Figure 4.1: Experience exceptional print clarity with high-definition output, ensuring sharp and clear text and graphics.

4.2 Supported Paper Types and Sizes

The A281M printer is designed exclusively for thermal paper. It does not support regular copy paper. It is compatible with five different paper sizes and three types:

• Өлчөмдөрү: US Letter (8.5'' x 11''), A4, 4.33'', 3.14'', 2.08''
• Түрлөрү: Roll thermal paper, Fold thermal paper, Ordinary thermal paper

Always use high-quality thermal paper to ensure optimal print results and printer longevity.

5. Техникалык тейлөө

5.1 Inkless Technology

This printer utilizes thermal technology, eliminating the need for ink cartridges, toner, or ribbons. This design prevents common ink-related issues such as clogs and messy clean-ups.

5.2 Тазалоо

To maintain print quality and extend the life of your printer, periodically clean the print head and paper path. Use a soft, lint-free cloth lightly dampизопропил спирти менен эритилсин. Тазалоодон мурун принтердин өчүрүлгөнүн жана электр кубатынан ажыратылганын текшериңиз.

5.3 Thermal Paper Care

Thermal paper can be sensitive to heat, light, and certain chemicals. Store thermal paper in a cool, dry place away from direct sunlight and heat sources to prevent fading and maintain print quality over time.

6. Кыйынчылыктарды

If you encounter issues with your TATTMUSE A281M printer, please refer to the following common problems and solutions:

7. Техникалык шарттар

8. Кепилдик жана колдоо

8.1 Кепилдик маалыматы

Your TATTMUSE A281M Portable Thermal Printer comes with a чектелген кепилдик. Please refer to the warranty card included in your package for specific terms and conditions, including coverage duration and claim procedures.

8.2 Кардарларды колдоо

For technical assistance, troubleshooting, or any inquiries regarding your product, please visit the official TATTMUSE store or contact customer support through the details provided in your product documentation. You can also find more information and resources on the TATTMUSE Store on Amazon.
