RESTMO RF Remote Controlled Sprinkler Timer

Продукт бүттүview

The RESTMO RF Remote Controlled Sprinkler Timer is designed to simplify your garden watering tasks. Featuring two independent zones and a convenient RF remote control, this timer allows for flexible and efficient irrigation management. Its durable construction with brass inlet and outlet ensures long-lasting performance in various outdoor conditions.

Image: RESTMO Sprinkler Timer with its remote control, showcasing the main unit and the compact remote.

Image: Visual representation of key features including remote control, timed watering, manual watering, rain delay, IP55 waterproof rating, filter washer, LCD display, durable material, and compact design.

Орнотуу колдонмосу

1. Батареяны орнотуу

The timer requires 2 AA alkaline batteries (not included) for operation. Ensure your hands are dry before handling batteries and the battery compartment.

1. Таймердин артындагы батарея бөлүкчөсүн табыңыз.
2. Батарея уясынын капкагын ачыңыз.
3. Туура полярдуулукту (+/-) камсыз кылып, эки жаңы AA щелочтуу батарейканы салыңыз.
4. Батарея бөлүгүнүн капкагын бекем жабыңыз.

Сүрөт: Жакын план view highlighting the pure brass inlet and outlet, emphasizing the upgraded waterproof screen for enhanced durability and leak-proof confidence.

2. Кранга жана шлангага туташтыруу

The timer features a 360-degree swivel pure brass inlet for easy attachment to your outdoor faucet and two brass outlets for connecting hoses.

1. Screw the timer's brass inlet onto your standard 3/4" outdoor faucet. Ensure it is hand-tightened securely to prevent leaks.
2. Connect your garden hoses to the two 3/4" brass outlets at the bottom of the timer.

3. Саатты коюу

Before programming, set the current time on the timer.

1. Turn the main dial to СААТТЫ КОЮ.
2. колдонуу +/- Саатты жана мүнөттү тууралоо үчүн баскычтарды басыңыз. OK button to switch between hour and minute settings.
3. Once the current time is set, turn the dial to any other position to save changes.

Иштөө нускамалары

1. Баштоо убактысын коюу

Define when you want your watering program to begin.

1. Turn the main dial to БАШТАЛГАН УБАКЫТ.
2. басыңыз L or R button to select the zone (Zone L or Zone R) you wish to program. You can program each zone independently.
3. колдонуу +/- buttons to set the desired start time. Press the OK button to switch between hour and minute settings.
4. Turn the dial to any other position to save changes.

2. Setting Watering Duration (How Long)

Specify how long each watering cycle should last (1 minute to 299 minutes).

1. Turn the main dial to КАНЧА УБАКЫТ.
2. басыңыз L or R button to select the zone.
3. колдонуу +/- buttons to set the watering duration. Press the OK сааттар менен мүнөттөрдүн ортосунда которулуу үчүн баскыч.
4. Turn the dial to any other position to save changes.

3. Setting Watering Frequency (How Often)

Determine how often the watering cycle repeats (every 1-12 hours or every 1-7 days).

1. Turn the main dial to КАЧАН.
2. басыңыз L or R button to select the zone.
3. колдонуу +/- buttons to set the watering frequency. You can choose between hours (1-12) or days (1-7).
4. Turn the dial to any other position to save changes.

ЭСКЕРТҮҮ: If "HOW LONG" is set to be greater than "HOW OFTEN", the watering cycle will be automatically skipped. To keep a zone always off, set the "HOW OFTEN" value to OFF using the +/- buttons.

4. Automatic Watering

Once programmed, activate the automatic watering schedule.

1. Turn the main dial to ON.
2. The LCD screen will display the next watering start time and the current time alternately when watering is OFF.
3. When watering is ON, the LCD screen will display the remaining time of the current watering program.

5. Кол менен сугаруу

Initiate immediate watering without affecting your programmed schedule.

1. Ensure the main dial is set to ON and the timer is not in Rain Delay mode.
2. көпкө басыңыз ОК/КОЛ баскычын 3 секунда басыңыз.
3. басыңыз L or R button to select the desired zone(s) for manual watering. You can select both zones simultaneously.
4. колдонуу +/- buttons to set the manual watering duration (1 to 299 minutes).
5. басыңыз OK button or wait for 3 seconds to start manual watering. The LCD screen will display the remaining time.
6. To cancel manual watering, turn the dial to ӨЧҮРҮҮ анан кайра ON.

Image: Demonstrates two options for manual watering: directly pressing buttons on the timer or using the remote control.

6. Жамгырдын кечиктирүү функциясы

Pause your watering schedule for a set period to conserve water during rainy weather.

1. Ensure the main dial is set to ON.
2. көпкө басыңыз КЕЧИКТИРҮҮ баскычын 3 секунда басыңыз.
3. колдонуу +/- buttons to select a delay period of 24, 48, or 72 hours.
4. басыңыз OK button or wait for 3 seconds to activate the rain delay. The timer will resume its schedule after the selected delay.
5. To cancel rain delay, turn the dial to ӨЧҮРҮҮ анан кайра ON.

Image: Illustrates the rain delay feature with options for 24, 48, and 72-hour delays, activated by long-pressing the delay button.

7. Алыстан башкарууну колдонуу

The included RF remote control allows you to manage your timer from up to 100ft (30m) away.

Алыстан башкарууну жупташтыруу:

1. With the timer dial set to ӨЧҮРҮҮ, long press the + button for 3 seconds until the LCD displays "PAIR".
2. Пульттагы баскычты басыңыз ЗОН button to select the desired zone number (1 or 2).
3. басыңыз ON button on the remote to pair. The timer's LCD will turn from "PAIR" to "OFF" upon successful pairing.

Алыстан башкарууну колдонуу:

1. Ensure the timer dial is set to ON.
2. басыңыз ЗОН button on the remote to select the desired zone (1 or 2).
3. колдонуу MIN+ / MIN- buttons to increase/decrease the manual watering duration.
4. басыңыз ON button to start watering for the preset duration.
5. басыңыз ӨЧҮРҮҮ button to stop watering.

Image: A person using the remote control from a distance to manage the sprinkler timer, illustrating the 100ft (30m) long-range capability.

Image: Collage showing the remote control being useful for different individuals, including a mother with children, an elderly person with a walker, and a person in a wheelchair, highlighting its accessibility and convenience.

8. Stopping Watering

To stop all watering and turn off the timer:

1. Turn the main dial to ӨЧҮРҮҮ. The timer will cease all watering operations and remain off.

Техникалык тейлөө

Cleaning the Filter Washer

The timer includes a filter washer at the inlet to prevent debris from entering the unit. Periodically check and clean this filter to ensure optimal water flow and prevent blockages.

1. Disconnect the timer from the faucet.
2. Remove the filter washer from the inlet.
3. Топтолгон калдыктарды кетирүү үчүн чыпканы агын суунун астында чайкаңыз.
4. Reinsert the clean filter washer into the inlet before reattaching the timer to the faucet.

Кышкы сактоо

To prevent damage from freezing temperatures, it is crucial to properly store your sprinkler timer during winter months.

• Таймерди крандан жана шлангдардан ажыратыңыз.
• Батареяларды таймерден алып салыңыз.
• Store the timer in a dry, frost-free location indoors.

Проблемаларды чечүү

Техникалык шарттар

• Модель номери: O-HT-1B-RF
• Материал: Brass (Inlet & Outlet)
• Түсү: Жашыл
• Продукциянын өлчөмдөрү: 5"D x 3"W x 5"H
• Элемент Салмагы: 1.14 фунт
• Сугаруу узактыгы: 1 - 299 мүнөт
• Сугаруу жыштыгы: Every 1 - 12 hours or Every 1 - 7 days
• Жумушчу суунун басымы: 8 - 120 psi (0.5 - 8.0 Bar)
• Макс. Flow Rate: 10 GPM (35 L/Min)
• Иштөө температурасы: 38…120°F (3…50°C)
• Кубат булагы: 2 x AA щелочтуу батарейкалар (киргизилген эмес)
• Суу өткөрбөйт рейтинги: IP55
• Алыстан башкаруу диапазону: 100 фут (30 м) чейин

Image: Detailed diagram showing the dimensions of the timer and a summary of its key specifications.

Кепилдик жана колдоо

Restmo products are designed for durability and performance. This product typically comes with a standard warranty, and some users have reported the ability to extend it up to five years by registering the device online. Please refer to the product packaging or the manufacturer's website for the most current warranty information and registration details.

For any questions, technical assistance, or support, please contact Restmo customer service. Contact information is often provided directly on the device or within the product packaging.
