VILTROX 50mm F2 Full Frame Lens for Sony Instruction Manual

Продукт бүттүview

The VILTROX 50mm F2 Full Frame Lens is a versatile and compact prime lens designed for Sony E-mount cameras. It offers a 50mm fixed focal length, ideal for portraiture, street photography, and general use. The lens boasts a sophisticated optical design with 13 elements in 9 groups, including specialized elements for superior image quality. Its STM autofocus motor ensures quick, quiet, and precise focusing, making it suitable for both still photography and video recording. The wide f/2.0 aperture allows for excellent low-light performance and beautiful background blur.

Негизги өзгөчөлүктөрү

• Superb Optics: Features a 9-group, 13-element structure, including 3 ED, 4 HR, and 1 Aspherical element for high image clarity.
• Full-frame E-mount Fast Prime Lens: AF 50mm F2.0 FE offers a focal length perfect for portraiture and a range of other subjects.
• STM (Stepping Motor): Provides reliable, fast, and quiet autofocus, ideal for both photos and video recording.
• 9-blade Circular Aperture: Enables effortless creation of smooth and pleasing background bokeh.
• Жеңил жана компакт: Weighing only 205g, the AF 50/2.0 Air lens delivers excellent image quality while maintaining portability.
• Outstanding Close-Up Performance: With a minimum focusing distance of 0.51m and a maximum magnification of 0.11x, it handles various shooting environments and subjects effectively.

Кутуда эмне бар

Upon unboxing your VILTROX 50mm F2 lens, you should find the following items:

• Объектив
• Линза капкагы
• Линзалык баштык
• Линза капкактары (алдыңкы жана арткы)

Figure 1: Included items in the VILTROX 50mm F2 lens package.

Жайгашуу

Линзаны тиркөө

1. Камераңыз өчүрүлгөнүн текшериңиз.
2. Remove the rear lens cap from the VILTROX 50mm F2 lens and the body cap from your Sony E-mount camera.
3. Линзанын цилиндриндеги ак индекс белгисин камераңыздын линза бекиткичиндеги тиешелүү ак индекс белгиси менен тегиздеңиз.
4. Insert the lens into the camera mount and rotate it clockwise until it clicks into place, indicating it is securely locked.

Figure 2: VILTROX 50mm F2 lens attached to a Sony camera body.

Линза капкагын бекитүү

The included lens hood helps to prevent stray light from entering the lens, reducing flare and ghosting, and also provides physical protection to the front element.

1. Линза капкагындагы кызыл чекитти линза цилиндринин алдыңкы жагындагы кызыл чекит менен тегиздеңиз.
2. Push the hood onto the lens and rotate it clockwise until it locks into place.

Figure 3: VILTROX 50mm F2 lens with the lens hood attached.

Линзаны иштетүү

Автофокус (AF)

The VILTROX 50mm F2 lens features an STM (Stepping Motor) for fast, quiet, and precise autofocus. This motor is highly effective for both still photography and video recording, ensuring smooth transitions and accurate subject tracking. The lens supports advanced autofocus features of compatible Sony cameras, including Eye-Detection AF.

Сүрөт 4: Алдыңкы view of the VILTROX 50mm F2 lens.

Кол менен фокустоо (MF)

For situations requiring precise control, the lens also supports manual focus. Simply switch your camera to manual focus mode, and rotate the focus ring on the lens barrel to adjust focus. The smooth rotation of the focus ring allows for fine adjustments.

Диафрагма Control

The lens features a bright f/2.0 maximum aperture, which is excellent for shooting in low-light conditions and for creating images with a shallow depth of field. The 9-blade circular aperture contributes to a pleasing and creamy bokeh, making subjects stand out from the background.

Figure 5: Close-up of the lens's front element, showing the aperture.

Орнотулган программаны жаңыртуу

The VILTROX 50mm F2 lens is equipped with a USB-C port for convenient firmware updates. Regularly checking for and installing the latest firmware ensures optimal performance, compatibility, and access to new features.

Figure 6: USB-C port for firmware updates located on the lens mount.

Расмий продукт Videos

Explore the capabilities of your VILTROX 50mm F2 lens with these official product videos from the manufacturer:

Техникалык тейлөө

Proper maintenance will extend the life and performance of your VILTROX 50mm F2 lens.

• Линзаны тазалоо: Use a soft, lint-free cloth or a lens brush to remove dust and debris from the lens surfaces. For stubborn smudges, use a specialized lens cleaning solution applied to a microfiber cloth, not directly to the lens.
• Сактагыч: When not in use, store the lens with both front and rear caps attached in a dry, cool place, away from direct sunlight and extreme temperatures. Using the included lens pouch can provide additional protection.
• Нымдуулуктан качыңыз: Keep the lens away from water and high humidity. If it gets wet, wipe it dry immediately.
• Этияттык менен мамиле кылуу: Линзаны түшүрүп алуудан же катуу соккуга кабылтуудан алыс болуңуз, анткени бул ички оптикалык элементтерге же механикалык компоненттерге зыян келтириши мүмкүн.

Проблемаларды чечүү

If you encounter issues with your VILTROX 50mm F2 lens, try the following troubleshooting steps:

• Автофокус иштебей жатат:
  • Линзанын камеранын корпусуна бекем орнотулганын текшериңиз.
  • Check your camera's focus mode settings (AF/MF).
  • Линзадагы жана камеранын корпусундагы электр контакттарын таза, кургак чүпүрөк менен сүртүңүз.
  • Update the lens firmware via the USB-C port.
• Image Quality Issues (e.g., soft images, excessive flare):
  • Ensure the lens elements are clean and free from smudges or dust.
  • Use the lens hood to minimize flare, especially when shooting towards bright light sources.
  • Check your camera's shutter speed and ISO settings to avoid motion blur or noise.
  • Ensure proper focus.
• Камера линзаны тааныбайт:
  • Remove and reattach the lens, ensuring it clicks into place.
  • Камераны кайра иштетиңиз.
  • Verify that your camera's firmware is up to date.

Техникалык шарттар

Кепилдик жана колдоо

VILTROX products are covered by a manufacturer's warranty. For specific details regarding your warranty period, coverage, and how to obtain service, please refer to the warranty card included in your product packaging or visit the official VILTROX website. For technical support, troubleshooting assistance, or any other inquiries, please contact VILTROX customer service through their official channels.
