Introduction
The SYNCO G2(A2) MAX is a professional wireless lavalier microphone system designed for clear and distortion-free audio capture. It is suitable for a wide range of applications including recording, live streaming, interviews, online classes, and presentations. This manual provides detailed instructions for setting up, operating, and maintaining your G2(A2) MAX system.
Продукт бүттүview
The SYNCO G2(A2) MAX system includes two transmitters (TX), one receiver (RX), and two 3.5mm headset microphones. Each component is designed for ease of use and reliable performance.
Figure 1: SYNCO G2(A2) MAX Wireless Microphone System components. This image displays the two compact transmitters (TX), one receiver (RX), and two included 3.5mm headset microphones, illustrating the complete system setup.
Компоненттер
- Бергич (TX): Captures audio via built-in microphone or external lavalier/headset mic. Features internal recording capability.
- Алуучу (RX): Receives audio signals from the transmitters and outputs to a recording device.
- 3.5mm Headset Microphones: Provides an alternative audio input for the transmitters, ideal for hands-free operation.
Figure 2: Two 3.5mm headset microphones. These microphones are designed for comfortable wear and provide clear audio input when connected to the SYNCO G2(A2) MAX transmitters.
Жайгашуу
- Заряддоо: Fully charge the transmitters and receiver using the provided USB-C cables before first use.
- Күйгүзүү: Press and hold the power button on both the TX units and the RX unit to turn them on. They will automatically pair.
- Микрофондорду туташтыруу:
- For built-in microphone use, ensure the TX unit is positioned correctly.
- To use the headset microphone, plug its 3.5mm connector into the MIC input port on the TX unit.
- Connect Receiver to Device:
- Use the included 3.5mm TRRS cable for smartphones, tablets, and laptops.
- Use the included 3.5mm TRS cable for DSLR cameras and camcorders.
Figure 3: Compatibility and Connection. This image illustrates how the SYNCO G2(A2) MAX system connects to various devices using its 3.5mm output, highlighting its universal compatibility with cameras, smartphones, and other recording equipment.
Иштөө нускамалары
TFT дисплей экраны
The bright, high-contrast TFT display screens on both the transmitters and receiver provide real-time information. This includes current recording mode, battery status, audio level, and gain settings, ensuring clear visibility in various lighting conditions.
Internal Recording (TX Units)
Each transmitter features 8GB of internal storage, allowing for approximately 24 hours of recording. This provides a reliable backup in case of wireless signal interruption or other audio recording quality issues.
- To start/stop internal recording: Long press the dedicated internal storage recording button on the TX unit for 3 seconds.
- One TX unit supports built-in recording for up to 5 hours at a time.
Figure 4: Internal Recording Feature. This image shows a user wearing a SYNCO G2(A2) MAX transmitter, with an overlay highlighting the device's display, indicating active recording and battery status, demonstrating the built-in recording capability.
Noise Reduction & Gain Control
The system incorporates a One-Touch Noise Cancellation feature to minimize background noise. Gain control is adjustable from 0 to 6 levels, allowing precise optimization of audio input levels.
- Ызы -чууну жокко чыгаруу: Press the designated button on the TX unit to activate or deactivate noise reduction.
- Пайданы тууралоо: Use the gain control buttons on the RX unit to increase or decrease the output audio level.
Figure 5: Noise Reduction and Gain Control. This graphic illustrates the effectiveness of the two-stage noise cancellation feature, showing a cleaner audio waveform 'After' activation. It also depicts the 6-level gain control on the receiver, allowing users to fine-tune audio input levels.
Output Modes (Receiver)
The receiver supports three output modes: Mono, Stereo, and Safety mode, providing flexibility for post-production and live scenarios.
- Моно режими: Combines audio from both transmitters into a single mono track.
- Стерео режими: Separates audio from each transmitter into distinct left and right channels.
- Коопсуздук режими: Provides a backup track at a lower volume level to prevent clipping or distortion. This mode is particularly useful for preventing whistling sounds.
Техникалык тейлөө
- Тазалоо: Түзмөктөрдү тазалоо үчүн жумшак, кургак чүпүрөктү колдонуңуз. Суюк тазалоочу каражаттарды же эриткичтерди колдонбоңуз.
- Сактагыч: Системаны күн нурунан жана экстремалдык температурадан алыс салкын, кургак жерде сактаңыз.
- Батареяга кам көрүү: For optimal battery life, avoid fully discharging the units frequently. Charge them regularly, even if not in use for extended periods.
- Кабельге кам көрүү: Туташтыргычтарга жана зымдарга зыян келтирбөө үчүн кабелдерди этият кармаңыз.
Проблемаларды чечүү
| Көйгөй | Мүмкүн себеп | Чечим |
|---|---|---|
| Аудио чыгышы жок |
|
|
| Бурмаланган же түшүнүксүз аудио |
|
|
| Кыска берүү диапазону |
|
|
| Internal recording not working |
|
|
Техникалык шарттар
- Модел: SYNCO G2(A2) MAX
- Трансмиссия түрү: 2.4 ГГц санарип
- Иштөө диапазону: Up to 656 ft / 200 m (Line-of-Sight)
- Internal Storage (TX): 8GB (Approx. 24 hours recording)
- Audio Output Modes: Mono, Stereo, Safety
- Көзөмөлдү алуу: 0-6 деңгээли
- Ызы-чууну азайтуу: One-Touch Noise Cancellation
- Дисплей: TFT экраны
- Байланыш: 3.5mm TRRS/TRS output
- ASIN: B0F43QL6F5
- Биринчи жеткиликтүү: 8-апрель, 2025-жыл
Figure 6: Long-Range Transmission. This image visually represents the impressive 656 feet (200 meters) line-of-sight transmission range of the SYNCO G2(A2) MAX, emphasizing its stable 2.4GHz digital transmission.
Колдонуу сценарийлери
The SYNCO G2(A2) MAX wireless microphone system is versatile and suitable for various professional and personal applications requiring high-quality audio capture.
- Интерviews: Dual transmitters allow for two-person interviews with clear, separate audio tracks.
- Vlogging & YouTube: Ideal for content creators needing reliable audio for their videos.
- Түз агым: Ensures professional sound quality for live broadcasts.
- Online Classes & Webinars: Provides clear voice transmission for educators and presenters.
- Presentations & Public Speaking: The headset microphones offer hands-free operation for speakers and coaches.
7 -сүрөт: С.tage Performance. A woman on stage utilizing the headset microphone for clear audio capture during a performance, demonstrating the system's suitability for live events.
Figure 8: Professional Presentation. A man presenting in a professional setting, wearing the headset microphone, highlighting its utility for teachers, speakers, and coaches.
Кепилдик жана колдоо
For warranty information and technical support, please refer to the official SYNCO webсайтка же түздөн-түз кардарларды тейлөөгө кайрылыңыз. Сатып алуу квитанциясын кепилдик дооматтары үчүн сатып алуунун далили катары сактаңыз.
SYNCO расмий Webсайт: www.syncoaudio.com
