Fujifilm үчүн Godox V1F тегерек баштуу камера жаркылдагычы - колдонуу боюнча колдонмо

1. Киришүү

The Godox V1F is a versatile round head camera flash designed for Fujifilm cameras, offering advanced features for professional and enthusiast photographers. This manual provides detailed instructions to help you effectively set up, operate, and maintain your flash unit.

Image: The Godox V1F Round Head Camera Flash, showcasing its distinctive round head design.

2. Коопсуздук чаралары

• Do not disassemble this product. If repairs become necessary, the product must be sent to an authorized maintenance center.
• Бул продуктуну кургак кармаңыз. Нымдуу кол менен кармабаңыз же сууга батырбаңыз.
• Балдар жетпеген жерде сактаңыз.
• Жаркылдатуучу блокту тез күйүүчү газдар, химиялык заттар же башка материалдар бар жерде колдонбоңуз.
• Do not touch the flash head immediately after use as it may be hot.
• Белгиленген батарейканы жана заряддагычты гана колдонуңуз.

3. Пакеттин мазмуну

Төмөндө тизмеленген нерселердин баары пакетиңизге камтылганын текшериңиз:

• 1x Godox V1-F Flash Unit
• 1x Li-ion Battery (7.2V/2600mAh)
• 1x Battery Charger (with cable)
• 1x USB линиясы
• 1x Мини стенд
• 1x коргоочу баштык
• 1x H-типтеги кронштейн
• 1x Колдонуучунун колдонмосу
• 1x Тазалоочу чүпүрөк

Image: A visual representation of the Godox V1F flash unit and its included accessories, such as the battery, charger, mini stand, and protection bag.

4. Продукциянын өзгөчөлүктөрү

4.1 Round Fresnel Head & Excellent Light Effects

The V1F features a round Fresnel head that distributes light evenly from the center to the edges, producing soft and natural light effects. The zooming head (28-105mm) allows for precise light control.

Image: A comparison demonstrating the even light distribution of the Godox V1F's round head versus a traditional rectangular speedlight.

4.2 Powerful Lithium Battery

Equipped with a 7.2V/2600mAh lithium battery, the V1F provides approximately 480 full power flashes and a fast 1.5-second recycle time, ensuring extended shooting performance.

Image: The Godox V1F flash unit alongside its high-performance lithium-ion battery, highlighting its 2600mAh capacity and 1.5-second recycle time.

4.3 Wireless Control & Compatibility

The built-in Godox 2.4G wireless X system offers all-in-one functionality, allowing the V1F to be used as a master or slave flash. It is compatible with Fujifilm cameras and can be triggered by Godox 2.4G series triggers (sold separately).

Image: The Godox V1F flash unit demonstrating its wireless capabilities and compatibility with various Godox 2.4G wireless X system triggers and other flash units.

4.4 Flexible Rotation & User-Friendly Design

The flash head offers wide-angle adjustment from 0° to 330° horizontally and -7° to 120° vertically, improving efficiency in bounce flash. The clear dot-matrix LCD panel and visual controls ensure ease of use. A rapid lock hot-shoe and smart magnetic mount for accessories enhance usability.

Image: Diagrams illustrating the flexible rotation angles of the Godox V1F flash head, along with a close-up of its clear LCD screen and quick lock hot-shoe mechanism.

Видео: Кыскачаview of the Godox V1 Round Head Camera Flash, highlighting its key features and design.

5. Орнотуу

5.1 Батареяны орнотуу

1. Жаркылдатуучу блоктогу батарея бөлүмүнүн капкагын ачыңыз.
2. Insert the 7.2V/2600mAh Li-ion battery, ensuring correct polarity.
3. Батарея уясынын капкагын бекем жабыңыз.

5.2 Жарыкты орнотуу

1. Slide the flash hot-shoe onto your Fujifilm camera's hot-shoe mount.
2. Push the quick lock mechanism to secure the flash firmly in place.

5.3 Күйгүзүү/өчүрүү

Жаркылдатууну күйгүзүү үчүн, КҮЙГҮЗҮҮ/ӨЧҮРҮҮ которгучун "КҮЙГҮЗҮҮ" абалына жылдырыңыз. LCD панели күйөт. Өчүрүү үчүн которгучту "ӨЧҮРҮҮ" абалына жылдырыңыз.

6. Иштөө нускамалары

6.1 TTL Autoflash Mode

In TTL mode, the flash automatically adjusts its output to achieve correct exposure. This mode supports 1/8000s High-Speed Sync (HSS) and Flash Exposure Compensation (FEC).

Image: The Godox V1F flash unit mounted on a camera, displaying its TTL automatic metering capabilities for accurate exposure in various lighting conditions.

6.2 Manual Flash Mode

In Manual mode, you can manually set the flash power output from 1/1 to 1/256. This provides full control over the light intensity.

6.3 Multi Flash Mode

Multi flash mode allows for a series of rapid flashes within a single exposure, useful for capturing multiple movements of a subject.

6.4 Моделдөө Лamp Операция

Камтылган LED моделдөө лamp can be adjusted in 10 steps (01 to 10) to provide a preview of how the light will fall on your subject before taking the shot.

6.5 Wireless Master/Slave Function

The V1F can act as a master unit to control other compatible Godox flashes or as a slave unit triggered by a master flash or transmitter. Refer to the specific wireless trigger's manual for detailed setup.

Video: Demonstrates the Godox V1 flash in various shooting scenarios, showcasing its versatility and light output in different environments.

7. Аксессуарлар

The V1F features a smart magnetic mount for quick attachment of various accessories, such as the AK-R1 kit (sold separately). These accessories include diffusers, grids, color filters, and barn doors to modify light output.

Image: The Godox V1F flash head with various magnetic accessories attached, demonstrating the ease of use and versatility of the magnetic mount system.

8. Техникалык тейлөө

8.1 Тазалоо

Жарк этүүчү аппаратты жумшак, кургак чүпүрөк менен дайыма тазалаңыз. өжөр кир үчүн, бир аз d колдонууamp cloth with mild detergent, then wipe dry. Avoid harsh chemicals or abrasive materials.

8.2 Батареяга кам көрүү

To prolong battery life, fully charge the battery before first use. Store the battery in a cool, dry place when not in use. If storing for extended periods, charge the battery to approximately 50% every three months.

9. Кыйынчылыктарды

9.1 Жарк этпейт

• Ensure the flash is securely mounted on the camera's hot-shoe.
• Check if the battery is fully charged and correctly inserted.
• Verify that the flash is powered on and the ready indicator light is green.
• Confirm that the camera's flash settings are correctly configured (e.g., external flash enabled, appropriate mode selected).

9.2 Inconsistent Flash Output

• Check battery level; low battery can lead to inconsistent output.
• Жаркылдак башынын масштабы линзанын фокустук аралыгына дал келгенин же автоматтык түрдө коюлганын текшериңиз.
• In TTL mode, ensure the subject is within the effective flash range.
• In Manual mode, adjust power output as needed for desired exposure.

10. Техникалык шарттар

11. Кепилдик жана колдоо

Кепилдик маалыматы жана техникалык колдоо үчүн расмий Godox'ту караңыз webсайтка кайрылыңыз же жергиликтүү дистрибьютериңиз менен байланышыңыз. Сатып алуу квитанциясын кепилдик дооматтары үчүн сатып алуунун далили катары сактаңыз.
