Introduction
The Amaran Pano 120c is a high-performance 120W RGBWW full-color LED video panel light designed for professional and enthusiast use. It offers a wide color temperature range, precise color accuracy, and various lighting effects, all controllable via an intuitive interface or a dedicated mobile application. Its compact and portable design, coupled with flexible power options, makes it suitable for diverse shooting environments.

Figure 1: Amaran Pano 120c Kit components. This image displays the main light panel, a softbox, a light control grid, a diffuser, an Amaran Ace Lock to Light Stand Adapter, a power adapter, cables, and the protected carrying case.
Эмне камтылган
Verify that all components listed below are present in your Amaran Pano 120c Kit:
- Amaran Pano 120c LED Panel Light
- Amaran Pano 120c Softbox
- Light Control Grid
- Диффузор
- Amaran Ace Lock to Light Stand Adapter
- Amaran 150W DC Locking Power Adapter
- Электр кабели
- Amaran Pano 120c Kit Carrying Case
Негизги өзгөчөлүктөрү
- Жогорку жарыктык жана түстүн тактыгы: 120W RGBWW full-color output with a wide CCT range of 2,300K-10,000K. Achieves CRI96 and TLCI97 for precise color rendering. Outputs up to 13,490 lux @ 1m (6,500K).
- 360° Full Color Control: Offers HSI (hue, saturation, intensity) and RGB color modes for comprehensive color customization. Includes green-magenta adjustment for accurate skin tones and 0-100% stepless brightness control.
- Ийкемдүү кубат параметрлери: Supports USB-C PD (Power Delivery) for versatile power solutions, including PD power banks and chargers. Features the Amaran Ace E-Lock quick-release mount for secure, cable-free operation with compatible power banks (battery not included).
- Компакт жана портативдик дизайн: Comparable in size to a tablet, weighing only 610g (1.3lbs), making it highly portable for on-location shoots, tight spaces, or mobile setups.
- 12 Built-in Lighting Effects: Includes Fireworks, Faulty Bulb, Lightning, TV, Pulsing, Strobe, Explosion, Fire, Paparazzi, Welding, Cop Car, and Party Lights.
- Ultra-Quiet Fan: Equipped with a low-noise fan cooling system, operating below 28dB, ensuring silent operation for sound-sensitive environments.
- Simplified Controls & App Integration: User-friendly color screen and dial for direct control, or wireless management via the Amaran app for multi-light setups and quick adjustments.

Figure 2: Multiple Light Modes. This image illustrates the extensive color temperature range (2,300K to 10,000K), dimming capabilities, and high color accuracy (CRI 96, TLCI 97) of the Amaran Pano 120c, along with its 360-degree full-color HSI mode.

Figure 3: One-Click Color Temperature Adjustment. This image highlights the ease of switching between cold and warm light, demonstrating the light's ability to restore natural skin tones and textures.

Figure 4: Multiple Power Supply Methods. The Amaran Pano 120c supports both DC-24V and USB-C PD 140W input, offering flexibility for various power sources including the Amaran Peak battery and other rechargeable batteries.

Figure 5: Compact and Portable. The Amaran Pano 120c is designed for easy transport, with dimensions similar to a laptop and a weight of just 1.6kg (3.5 lbs), making it ideal for travel.

Figure 6: Creative Lighting Effects. The Amaran Pano 120c offers 12 pre-set lighting effects, which can be controlled and customized via the Amaran app for various creative scenarios.

Figure 7: Ultra-Quiet Operation. The integrated fan cooling system keeps noise levels below 28dB, making the Pano 120c suitable for recording environments where silence is critical.
Орнотуу колдонмосу
- Компоненттерди таңгактан чыгаруу: Carefully remove all items from the carrying case. Ensure all listed components in the "What's Included" section are present.
- Attach to Light Stand: Secure the Amaran Ace Lock to Light Stand Adapter to your light stand. Then, attach the Amaran Pano 120c light panel to the adapter. Ensure it is firmly secured to prevent accidental falls.
- Туташуу кубаты:
- DC кубаттуулугу: Connect the 150W DC Locking Power Adapter to the DC-24V input port on the light panel and plug it into a suitable power outlet.
- USB-C PD Power: For portable operation, connect a USB-C PD power bank (outputting above 140W) to the USB-C PD input port.
- Amaran Ace E-Lock: If using a compatible Amaran Peak battery, attach it directly to the Ace E-Lock contacts for cable-free power.
- Attach Modifiers (Optional):
- Софтбокс: Attach the Amaran Pano 120c Softbox to soften the light output.
- Light Control Grid: For more directional light and spill control, attach the Light Control Grid to the softbox.
- Диффузор: Use the diffuser for a softer, more even light spread.
- Күйгүзүү: Press the power button on the light panel to turn it on.
Video 1: Amaran Pano 60c/120c Overview. This video demonstrates the portability, quick setup, and various applications of the Amaran Pano series lights, including power options and creative uses in different environments.
Иштөө нускамалары
Кол менен башкаруу
The Amaran Pano 120c features an intuitive color screen and a multi-function dial for direct control:
- Жарыктыкты жөндөө: Rotate the main dial to adjust the light intensity from 0% to 100%.
- Color Temperature (CCT) Mode: Navigate to CCT mode using the menu buttons. Rotate the dial to change the color temperature between 2,300K and 10,000K.
- HSI режими: In HSI mode, adjust Hue (H), Saturation (S), and Intensity (I) independently using the dial and corresponding buttons.
- RGB режими: Directly control Red, Green, and Blue values to achieve desired colors.
- Жарык эффекттери: Select from the 12 built-in lighting effects (Fireworks, Faulty Bulb, Lightning, TV, Pulsing, Strobe, Explosion, Fire, Paparazzi, Welding, Cop Car, Party Lights) and adjust their parameters as needed.
App Control (Amaran App)
For advanced control and multi-light setups, download and connect to the Amaran app via Bluetooth:
- Колдонмону жүктөп алуу: Издөө "Amaran" in your device's app store and install the official application.
- Bluetooth иштетүү: Ensure Bluetooth is enabled on your mobile device and on the Amaran Pano 120c.
- Түзмөктү жупташтыруу: Open the Amaran app and follow the on-screen instructions to discover and pair with your Pano 120c.
- Алыстан башкаруу: Once connected, you can remotely adjust all parameters, including brightness, CCT, HSI, RGB, and trigger lighting effects. The app also allows for custom scene creation and management of multiple Amaran lights simultaneously.
Техникалык тейлөө
- Тазалоо: Use a soft, dry cloth to clean the light panel and accessories. Do not use abrasive cleaners or solvents.
- Сактагыч: When not in use, store the light and its accessories in the provided carrying case in a cool, dry place, away from direct sunlight and extreme temperatures.
- Желдеткичти тейлөө: Ensure the fan vents are clear of dust and debris to maintain optimal cooling performance.
- Кабельге кам көрүү: Avoid sharp bends or kinks in power cables to prevent damage.
Проблемаларды чечүү
| Көйгөй | Мүмкүн себеп | Чечим |
|---|---|---|
| Жарык күйбөйт. | No power, loose connection, faulty power adapter/battery. | Check power source and connections. Ensure power adapter is functioning or battery is charged. |
| Колдонмо жарыкка туташа албайт. | Bluetooth off, light not in pairing mode, app issue. | Ensure Bluetooth is on for both devices. Restart the light and the app. Try re-pairing. |
| Жарык бүлбүлдөп же өзүн туура эмес алып жүрөт. | Unstable power, overheating, firmware issue. | Check power supply stability. Ensure proper ventilation. If problem persists, contact support. |
| Желдетүүчү ызы-чуу. | Dust accumulation, operating in high temperature. | Clean fan vents. Ensure adequate airflow around the unit. |
Техникалык шарттар
| Атрибут | Нарк |
|---|---|
| Бренд | Amaran |
| Модел | Pano 120c |
| Чыгуу күчү | 120 Вт |
| Түс температурасы (CCT) | 2,300K - 10,000K |
| Түс тактыгы | CRI 96, TLCI 97 |
| Жарыктандыруу эффекттери | 12 (Fireworks, Faulty Bulb, Lightning, TV, Pulsing, Strobe, Explosion, Fire, Paparazzi, Welding, Cop Car, Party Lights) |
| Контролдоо ыкмалары | On-board dial/screen, Bluetooth App Control |
| Power Input | USB-C PD (140W+ required), DC-24V |
| Элемент Салмагы | 8.83 фунт (болжол менен 4 кг) |
| Пакеттин өлчөмдөрү | 17.55 x 11.6 x 5 дюйм (болжол менен 44.6 x 29.5 x 12.7 см) |
Кепилдик жана колдоо
For warranty information, technical support, or service inquiries, please refer to the official Amaran webсайтка же кардарларды тейлөө бөлүмүнө кайрылыңыз. Сатып алуу квитанциясын кепилдик дооматтары үчүн сатып алуунун далили катары сактаңыз.
Official Amaran Webсайт: www.aputure.com/amaran/
