1. Киришүү
This manual provides detailed instructions for operating the Sony Alpha 7 IV (A7IV) mirrorless camera. It covers essential functions, advanced settings, and practical tips to help users capture high-quality photos and professional-grade videos. Familiarize yourself with the camera's features and controls to unlock its full potential.
2. Баштапкы орнотуу
2.1. Кутучадан чыгаруу жана батарейканы орнотуу
Upon unboxing your Sony A7IV, ensure all components are present: camera body, battery pack, AC adapter, USB-C cable, shoulder strap, and body cap. Insert the fully charged battery into the battery compartment located at the bottom of the camera. Close the compartment cover securely.
2.2. Батареяны заряддоо
Connect the camera to the AC adapter using the supplied USB-C cable. The charging indicator lamp will illuminate. Charging is complete when the lamp turns off. It is recommended to fully charge the battery before first use.
2.3. Эстутум картасын салуу
The A7IV supports SD cards (UHS-I/II compatible) and CFexpress Type A cards. Open the memory card slot cover on the side of the camera. Insert the memory card with the contacts facing the correct direction until it clicks into place. Close the cover. Format the memory card before initial use via the camera's menu system to ensure optimal performance.
2.4. Объективди бекитүү
Remove the body cap from the camera and the rear lens cap from the lens. Align the white index mark on the lens with the white index mark on the camera body. Mount the lens by rotating it clockwise until it clicks into place. To detach, press the lens release button and rotate the lens counter-clockwise.
3. Камераны иштетүү
3.1. Күйгүзүү / Өчүрүү
To power on the camera, slide the ON/OFF switch located around the shutter button to the "ON" position. To power off, slide it to "OFF".
3.2. Сүрөт тартуунун негизги режимдери
The mode dial allows selection of various shooting modes:
- Программанын автоматтык режими (P): Камера оптималдуу экспозиция үчүн диафрагманы жана жабуунун ылдамдыгын орнотот.
- Диафрагма артыкчылыктуулугу (A): Колдонуучу диафрагманы, камера жапкыч ылдамдыгын орнотот. Талаанын тереңдигин башкаруу үчүн идеалдуу.
- Жабык приоритети (S): Колдонуучу жапкыч ылдамдыгын, камера диафрагманы орнотот. Кыймылдын бүдөмүктүгүн башкаруу үчүн идеалдуу.
- Кол менен (M): User sets both aperture and shutter speed.
- Акылдуу Авто: Камера автоматтык түрдө көрүнүштү аныктайт жана оптималдуу орнотууларды колдонот.
3.3. Автофокус системасы
The A7IV features advanced Real-time Tracking and Real-time Eye AF. To activate, half-press the shutter button. The camera will automatically detect and track subjects. Customize AF settings via the menu for specific scenarios (e.g., AF-C for continuous tracking, AF-S for single shot).
3.4. Видео жаздыруу
Switch the Still/Movie/S&Q dial to the movie icon. Press the MOVIE button to start and stop recording. The A7IV supports 4K video recording up to 60p. Adjust video settings such as frame rate, resolution, and picture profiles in the camera's menu.
3.5. Меню навигациясы
Press the MENU button to access the camera's settings. Use the control wheel or multi-selector to navigate through tabs and options. Press the center button to confirm selections. The touch screen can also be used for navigation.
4. Техникалык тейлөө жана кам көрүү
4.1. Камеранын корпусун тазалоо
Камеранын корпусун жумшак, кургак чүпүрөк менен сүртүңүз. Кежир кир үчүн, чүпүрөктү жеңил колдонуңуз dampened with water. Avoid using organic solvents like alcohol or thinner, as they can damage the finish.
4.2. Объективди тазалоо
Use a blower brush to remove dust from the lens surface. For smudges or fingerprints, use a lens cleaning solution and a microfiber cloth specifically designed for optics. Clean gently in a circular motion from the center outwards.
4.3. Сенсорду тазалоо
If dust spots appear on images, the image sensor may need cleaning. The A7IV has an automatic sensor cleaning function. If manual cleaning is required, consult a professional service center or use a specialized sensor cleaning kit with extreme caution.
4.4. Сактоо
When not in use for extended periods, remove the battery and store the camera in a cool, dry place away from direct sunlight and humidity. Use desiccant packets if storing in humid environments.
5. Кыйынчылыктарды
5.1. Камера күйбөй жатат
- Батарея толук заряддалганын жана туура салынганын текшериңиз.
- Батарея контакттары таза экенин текшериңиз.
- Башка, толук заряддалган батарейканы колдонуп көрүңүз.
5.2. Сүрөттөр бүдөмүк
- Check focus mode and ensure the subject is in focus.
- Verify shutter speed is fast enough to prevent motion blur, especially in low light or with moving subjects.
- Линзанын таза жана тактар жок экенин текшериңиз.
- Check if image stabilization (SteadyShot) is enabled if shooting handheld.
5.3. Эстутум картасынын катасы
- Эстутум картасын кайра салыңыз.
- Try formatting the card (note: this will erase all data).
- Use a different, compatible memory card.
- Картанын жазуудан корголгон эместигин текшериңиз.
5.4. Overheating Warning During Video Recording
High-resolution video recording can generate heat. If an overheating warning appears, stop recording and allow the camera to cool down. Reduce recording resolution or frame rate, or use an external monitor/recorder if extended recording is necessary.
6. Техникалык шарттар
The following specifications are typical for the Sony Alpha 7 IV (ILCE-7M4) camera body. Please refer to the official Sony webэң так жана актуалдуу маалымат алуу үчүн сайт же продукт документациясы.
| Өзгөчөлүк | Деталь |
|---|---|
| Сенсор түрү | 33.0 MP Full-Frame Exmor R CMOS Sensor |
| Сүрөт процессору | BIONZ XR |
| Автофокус системасы | 759-point Phase-Detection AF, Real-time Tracking, Real-time Eye AF |
| Видео жаздыруу | 4K 60p (Super 35mm), 4K 30p (Full-Frame), 10-bit 4:2:2 internal recording |
| ISO сезгичтиги | 100-51200 (50-204800 чейин кеңейтилиши мүмкүн) |
| Image Stabilization | 5-ок денедеги сүрөттү турукташтыруу (IBIS) |
| Viewтапкыч | 3.68m-dot EVF |
| ЖК Monitor | 3.0-inch 1.03m-dot Vari-angle Touchscreen |
| Memory Card Slots | Dual slots (CFexpress Type A / SD UHS-II compatible) |
| Байланыш | Wi-Fi, Bluetooth, USB-C, HDMI (Type-A), Microphone, Headphone |
7. Кепилдик маалыматы
Sony products typically come with a limited manufacturer's warranty covering defects in materials and workmanship for a specified period from the date of purchase. The exact terms and duration of the warranty may vary by region and product. Please refer to the warranty card included with your camera or visit the official Sony support webсиздин аймагыңызга тиешелүү толук кепилдик маалыматы үчүн сайтты караңыз.
Keep your proof of purchase (receipt or invoice) as it is required for any warranty claims.
8. Кардарларды колдоо кызматы
For further assistance, technical support, or service inquiries, please contact Sony customer support through the following channels:
- Sony компаниясынын расмий колдоо кызматы Webсайт: Visit sony.com/electronics/support for FAQs, software updates, and service information.
- Продукцияны каттоо: Жаңыртууларды жана колдоону алуу үчүн продуктуңузду онлайн каттаңыз.
- Телефондук колдоо: Refer to your product documentation or the Sony support webжергиликтүү байланыш номерлери үчүн сайт.
When contacting support, please have your camera's model name (ILCE-7M4) and serial number ready.
9. Visual Aids
The following images depict the cover of the "SONY A7IV USER GUIDE" book, which this manual is based upon. These are not images of the Sony A7IV camera itself.
1-сүрөт: Front cover of the SONY A7IV USER GUIDE book. It features the title "SONY A7IV User Guide" with a subtitle "A Step-by-Step Manual for Capturing Stunning Photos and Professional Videos" and an image of a person holding a Sony camera, with the author's name "RAYMOND KELLAM" at the bottom left.
2-сүрөт: Back cover of the SONY A7IV USER GUIDE book. The cover is predominantly black with "Copyrighted Material" text at the top and bottom, and a barcode with ISBN 979-8285643012 visible in the bottom right corner.
