Introduction
This manual provides comprehensive instructions for the installation and operation of your BRIKSMAX 2.0 LED Light Kit, specifically designed for the LEGO Icons 10351 Sherlock Holmes Book Nook set. Following these guidelines will help you successfully integrate the lighting system and enhance your LEGO model's display.
Image 1: The LEGO Sherlock Holmes Book Nook model illuminated by the BRIKSMAX LED Light Kit.
Пакеттин мазмуну
Орнотууну баштоодон мурун, пакетиңизде төмөндө келтирилген бардык компоненттер бар экенин текшериңиз:
- LED Light Kit (various light types and quantities)
- Кагаз нускамалары
- Колдонуучунун колдонмосу
- AA батарея кутучасы (батареялар комплектке кирбейт)
- USB кубат кабели
- Кеңейтүү тактасы
- Building Block Type Battery Box
- Assorted Light Bricks (e.g., 1x4 Light Brick - Warm White, 1x2 Light Brick - Warm White)
Image 2: All components included in the BRIKSMAX LED Light Kit.
Орнотуу жана орнотуу
The BRIKSMAX 2.0 Light Kit is designed for integration with your LEGO Icons 10351 Sherlock Holmes Book Nook. Follow the detailed paper instructions provided in your kit for step-by-step guidance. Key aspects of the installation include:
- Зымдарды башкаруу: Utilize the newly designed wire organizer parts to conceal wires effectively. This prevents breakage and ensures a neat, integrated appearance within your LEGO model.
- Компоненттик интеграция: Lights and expansion boards are designed to fit within the existing brick structure, minimizing exposed components for a cleaner aesthetic.
- Ийкемдүү жайгаштыруу: Independent accessories allow for flexible installation. You can adjust the placement of light points to achieve desired display effects.
Сүрөт 3: Мисample of wire management using BRIKSMAX organizer parts.
Refer to the included paper instructions for specific brick removal and light placement details. Ensure all connections are secure to prevent intermittent lighting.
Иштөө нускамалары
Once the light kit is fully installed and connected, you can power it on using either the USB cable or the AA Battery Box.
- USB Power: Connect the provided USB cable to the light kit's expansion board and then to a compatible USB power source (e.g., a USB wall adapter, power bank, or computer USB port).
- Батарея кубаттуулугу: Insert the required AA batteries (not included) into the AA Battery Box. Connect the battery box to the light kit's expansion board.
The lights will illuminate upon connection to a power source. There are no additional switches on the light kit itself; power is controlled by connecting or disconnecting the power source.
Image 4: Visualizing the LEGO model with lights on and off.
Техникалык тейлөө
To ensure the longevity and optimal performance of your BRIKSMAX LED Light Kit, consider the following maintenance tips:
- Тазалоо: Gently dust the LED components and wires with a soft, dry cloth. Avoid using liquid cleaners directly on the electrical components.
- Колдонуу: When moving or disassembling your LEGO model, handle the light kit components carefully to avoid bending or breaking wires.
- Сактагыч: If storing the model for an extended period, disconnect the power source (remove batteries or unplug USB cable) to prevent battery drain or potential damage.
Проблемаларды чечүү
If you encounter any issues with your BRIKSMAX LED Light Kit, please refer to the following common solutions:
- Жарыктар күйбөйт:
- Ensure the power source (USB cable or battery box) is correctly connected and functional.
- Батареяларды колдонсоңуз, алардын туура салынганын жана заряды жетиштүү экендигин текшериңиз.
- Verify all wire connections to the expansion board and individual lights are secure.
- Жеке чырактар иштебей жатат:
- Check the specific wire connection for the non-functional light.
- Inspect the wire for any visible damage or kinks.
- Жаркылдаган жарыктар:
- Бардык байланыштардын бекем жана бош эмес экенине ынаныңыз.
- If using battery power, low battery charge can cause flickering. Replace batteries if necessary.
Бул кадамдар маселени чечпесе, кардарларды колдоо кызматына кайрылыңыз.
Техникалык шарттар
| Өзгөчөлүк | Деталь |
|---|---|
| Бренд | BRIKSMAX |
| Модель номери | 10351 (BX761) |
| Материал | Пластик |
| Жарык булагы түрү | LED |
| Жарык булактарынын саны | Multiple individual LEDs (e.g., 19 total as per kit contents) |
| Тtage | 5 вольт (ток) |
| Power Source | USB or AA Battery Box (Batteries not included) |
| Ассамблея талап кылынат | Ооба |
| Ички/тышкы колдонуу | Indoor |
| Элемент Салмагы | 180 грамм (6.3 унция) |
| Продукциянын өлчөмдөрү | 6.5 x 4.72 x 1.57 дюйм |
| Өндүрүүчүнүн сунуш кылган курагы | 8 жаш жана андан жогору |
Кепилдик жана колдоо
BRIKSMAX LED lighting kits are manufactured using safe and reliable materials. We are committed to providing quality products and support.
- Бузулган же жок бөлүктөрү: If you receive a kit with damaged or missing components, please contact us directly for a replacement.
- Кардарларды тейлөө: For any questions, concerns, or assistance with installation and operation, please reach out to BRIKSMAX customer support. Refer to the contact information provided in your product packaging or on the official BRIKSMAX webсайт.
