1. Киришүү
Thank you for choosing the Clemas H6 Rechargeable Camping Light. This versatile lighting solution is designed for various outdoor and emergency situations, offering powerful illumination, flexible adjustment, and convenient features. Please read this manual thoroughly before use to ensure proper operation and maintenance.
2. Коопсуздук маалыматы
- Always ensure the device is fully charged before its first use.
- Жарыкты узак убакыт бою өтө жогорку температурага же түз күн нуруна дуушар кылбаңыз.
- Балдар жетпеген жерде сактаңыз.
- Do not attempt to disassemble or modify the device, as this will void the warranty and may cause damage or injury.
- Кубаттоо үчүн берилген кубаттоочу кабелди же сертификатталган Type-C кабелин гана колдонуңуз.
- Ensure the light is stable when extended to its full height to prevent tipping.
3. Пакеттин мазмуну
Пакетиңизде бардык буюмдар бар экенин текшериңиз:
- Campжарык берүүчү блок
- Campingamp Stand (Telescopic Tripod)
- Алыстан башкаруу
- Заряддоо кабели (Type-C)
- Storage Box for Light Unit
- Storage Bag for Stand
- Ground Nails (for securing stand)
- User Manual
3.1-сүрөт: Пакеттин мазмуну
4. Продукт бүтүп калдыview
The Clemas H6 features a compact design with powerful lighting capabilities. Key components include the main light unit with four adjustable LED panels, a telescopic tripod stand, and a wireless remote control.
Figure 4.1: Clemas H6 Camping Light Components
5. Орнотуу нускамалары
5.1 Алгачкы заряддоо
Биринчи колдонуудан мурун, сamping light unit. Connect the provided Type-C charging cable to the charging port on the light unit and to a 5V/2.4A USB power adapter (not included). A full charge takes approximately 5.5 hours.
Figure 5.1: Charging the Light Unit
5.2 Assembling the Stand and Light
- L бураңызamp: Gently screw the main light unit into the threaded socket at the top of the stand bracket.
- Loosen Tension Knob: Locate the tension knob on the stand bracket and loosen it to allow movement.
- Unfold Tripod: Carefully unfold the tripod legs until they are fully extended and stable.
- Бийиктигин тууралоо: Lift the bracket by hand and rotate it to adjust the height of the light to your desired position, from 48 inches (4 feet) to 98 inches (8.2 feet). Secure the height by tightening the tension knob.
Figure 5.2: Stand Assembly Steps
6. Иштөө нускамалары
6.1 Күйгүзүү/өчүрүү
Press the power button on the light unit to turn it on or off. The light will remember your last used settings.
6.2 Жарыктык жана түс температурасын жөндөө
The Clemas H6 offers 10 brightness levels and 3 color temperatures:
- Салкын ак жарык: 8300K
- Табигый жарык: 3100K
- Жылуу жарык: 1700K
Use the 'M' button on the light unit or remote to cycle through color temperatures. Use the '+' and '-' buttons for stepless brightness adjustment (long press for continuous change).
Figure 6.1: Lighting Adjustment and Color Modes
6.3 Алыстан башкарууну колдонуу
The included remote control allows convenient operation from up to 33 feet away. Маанилүү: Before using the remote, always manually turn on the light unit using its physical power button.
Figure 6.2: Remote Control in Use
6.4 SOS Mode
For emergency situations, the light features an SOS flash mode. Activate this mode by pressing the dedicated SOS button on the light unit or remote. The lamp head is IPX7 rated, and the body is IPX5 water-resistant, making it suitable for various weather conditions.
Figure 6.3: SOS Mode and Water Resistance
6.5 Versatile Placement Options
- Telescopic Stand: Adjust height from 4 to 8.2 feet for wide area illumination.
- Магниттик база: The base contains 6 Neodymium magnets, allowing secure attachment to metal surfaces like car hoods or workshop benches.
- Асма илгич: A metal hook at the bottom allows the light to be hung upside down from branches, ropes, tents, or backpacks.
Figure 6.4: Magnetic Base and Hanging Hook
Figure 6.5: Multifunctional Uses
7. Батарея жана заряддоо
The Clemas H6 is equipped with a high-capacity 14000mAh Lithium-Ion battery, providing extended illumination. It also functions as a portable power bank.
- Батареянын иштөө мөөнөтү: Up to 3.5 hours at maximum brightness (all 4 panels) and up to 80 hours at minimum brightness (1 panel).
- Заряддоо киргизүү: 5V/2.4A via Type-C port.
- Power Bank чыгаруу: 5V/2.4A via USB-A port for charging mobile devices.
Figure 7.1: Battery Capacity and Power Bank Function
8. Техникалык тейлөө
- Тазалоо: Жарык блогун сүртүп, жумшак, d менен тургузуңузamp кездеме. Абразивдүү тазалагычтарды же эриткичтерди колдонбоңуз.
- Сактагыч: When not in use, store the light and stand in their respective storage cases/bags in a cool, dry place. Ensure the device is fully charged before long-term storage to preserve battery health.
- Батареяга кам көрүү: Recharge the battery at least once every three months if stored for extended periods to prevent deep discharge.
9. Кыйынчылыктарды
| Көйгөй | Мүмкүн себеп | Чечим |
|---|---|---|
| Жарык күйбөйт. | Батарея түгөнүп калды. | Charge the light unit fully. |
| Пульт иштебей жатат. | Light unit not manually turned on. | Ensure the light unit is first turned on using its physical power button. |
| Жарыктын чыгышы күңүрт. | Low battery or brightness setting. | Recharge the unit or increase brightness using '+' button on light/remote. |
| Stand is unstable. | Tripod legs not fully extended or tension knob loose. | Ensure tripod legs are fully spread and tension knob is tightened. Use ground nails on soft surfaces. |
10. Техникалык шарттар
| Өзгөчөлүк | Деталь |
|---|---|
| Модель номери | H6 |
| Light Output (Max) | 6000 Lumens |
| Батарея сыйымдуулугу | 14000 мАч литий-ион |
| Заряддоо убактысы | Болжол менен 5.5 саат (Тип-C аркылуу) |
| Батареянын иштөө мөөнөтү (максималдуу жарыктык) | Болжол менен 3.5 саат |
| Батареянын иштөө мөөнөтү (минималдуу жарыктык) | Болжол менен 80 саат |
| Бийиктигин тууралоо | 48дан 98 дюймга чейин (4тен 8.2 футка чейин) |
| Түс температурасы | 8300K (Cool), 3100K (Natural), 1700K (Warm) |
| Сууга туруктуулук деңгээли | Lamp: IPX7, Body: IPX5 |
| Материал | Металл, пластик |
| Элемент Салмагы | 6.73 фунт |
| Продукциянын өлчөмдөрү (бүктөлгөн) | 7.09 x 3.54 x 34.25 дюйм |
11. Кепилдик жана колдоо
Clemas products are designed for durability and performance. For any questions about your order or the product, please contact our customer service team. The manufacturer is Clemas.
Байланыш маалыматы: Please refer to the packaging or the official Clemas website for the most up-to-date customer support contact details.
11.1-сүрөт: Продукцияны таңгактоо
Figure 11.2: Warranty Information on Packaging
