1. Киришүү
This manual provides comprehensive instructions for the Jennov 5MP Wireless Security Camera System P48 Add-On Camera. This camera is designed for both outdoor and indoor surveillance, offering 5MP ultra-HD resolution, night vision, motion detection, and IP66 weatherproofing. It operates as an add-on unit for the Jennov P48 System (ASIN: B0FC22WYKN) and requires a dedicated outlet power source for continuous operation. Please read this manual thoroughly before installation and use to ensure optimal performance and safety.
2. Кутуда эмне бар
Кутучаны этияттык менен ачып, бардык буюмдардын бар экенин жана жакшы абалда экенин текшериңиз. Эгерде кандайдыр бир буюмдар жок болсо же бузулуп калса, кардарларды тейлөө кызматына кайрылыңыз.
- 1 x Security Camera Outdoor Wireless
- 1 x Power Adapter for Camera
- Монтаждоо бурамалар пакети
- User Manual
Figure 2.1: Included Components (Note: This product is an add-on camera, not the full system shown.)
3. Продукт бүтүп калдыview
The Jennov P48 Add-On Camera is a high-performance wireless security camera designed to expand your existing Jennov P48 NVR system. It features advanced imaging and connectivity for reliable surveillance.
3.1 Негизги өзгөчөлүктөрү
- 5MP Ultra-HD Resolution: Так жана деталдуу видео азыктарды көрсөтөтtage.
- Зымсыз туташуу: Connects to the NVR without complex wiring.
- Plug-and-Play Power: Each camera is powered by an independent outlet adapter for uninterrupted operation.
- Акылдуу аныктоо: Motion detection with instant alerts and recording.
- Түнкү көрүнүш: ачык-айкын foo камсыз кылатtage in low-light conditions up to 15 meters.
- IP66 аба ырайы: Designed to withstand various outdoor weather conditions (-20°C to 60°C).
- Эки тараптуу аудио: Камера аркылуу реалдуу убакыт режиминде байланышууга мүмкүндүк берет.
- Pan/Tilt функциясы: Толук камтуу үчүн 355° горизонталдык жана 90° вертикалдык айланууну сунуштайт.
3.2 Камеранын компоненттери
Figure 3.1: Jennov P48 Add-On Camera
- Камера линзасы: Video foo тартатtage.
- Инфракызыл диоддор: Түнкү көрүнүш үчүн жарыктандырууну камсыз кылыңыз.
- Spotlight LEDs: Enhance color night vision and act as a deterrent.
- Микрофон: Эки тараптуу байланыш үчүн аудио жаздырат.
- Баяндамачы: Эки тараптуу байланыш үчүн аудио чыгарат.
- Антенналар: For wireless signal transmission.
- Электр порту: Кубат адаптерине туташат.
- Монтаждык база: Дубалга же шыпка орнотуу үчүн.
4. Орнотуу нускамалары
This section guides you through the physical installation and initial connection of your add-on camera to the Jennov P48 NVR system.
4.1 Сайтты тандоо
Каалаган жерди камсыз кылган жерди тандаңыз viewing angle and is within range of your Jennov P48 NVR's wireless signal. Ensure a power outlet is accessible for the camera's power adapter. The camera is IP66 weatherproof, suitable for outdoor use.
Figure 4.1: Optimal Camera Placement for 2.4GHz WiFi Coverage
4.2 Физикалык орнотуу
- Бургулоо пункттарын белгилөө: Use the provided hole sticker or camera base as a template to mark the screw positions on the wall or ceiling.
- Бургулоо тешиктери: Drill pilot holes at the marked positions. Insert wall anchors if installing on masonry or drywall.
- Камераны орнотуу: Берилген бурамалар менен камеранын бекитүүчү негизин бетке бекитиңиз.
- Бурчту тууралоо: Loosen the adjustment screws on the camera body to set the desired viewing angle, then tighten them to secure the position.
Figure 4.2: Installation Options (Ceiling-mounted and Wall-mounted)
4.3 Кубат туташтыруу
Connect the camera's power adapter to the camera's power port, then plug the adapter into a standard electrical outlet. The camera will power on automatically.
4.4 Pairing with NVR (Add-On Camera)
The Jennov P48 Add-On Camera is designed to automatically pair with your existing Jennov P48 NVR system. Once powered on, the camera should establish a wireless connection with the NVR. If the camera does not appear on your NVR monitor:
- Access the NVR's menu and navigate to the 'Camera Management' or 'Channel Setup' section.
- Select an unused channel and initiate the 'Add Camera' or 'Wireless Pairing' function.
- The NVR will search for available cameras. Once detected, select your camera to add it to the system.
Figure 4.3: NVR System Connection Diagram
5. Иштөө нускамалары
This section details how to utilize the various features of your Jennov P48 Add-On Camera through the NVR system and the mobile application.
5.1 Live View жана Жаздыруу
Once connected to the NVR, you can view the live feed from your camera on the NVR's connected monitor. The system will automatically record footage based on your NVR's settings (e.g., continuous, motion-triggered).
5.1-сүрөт: Көп камералуу түз эфир View NVRде
5.2 Кыймылды аныктоо жана эскертүүлөр
The camera features smart motion detection. When motion is detected, the system can trigger recording, send alerts to your mobile device, and activate the camera's spotlight and siren.
- Аныктоо зоналарын орнотуу: Through the NVR or mobile app, you can define specific areas within the camera's view for motion detection, minimizing false alarms.
- Alert Configuration: Customize alert types (push notifications, email) and schedules.
Figure 5.2: Customized Detection Areas
Figure 5.3: Spotlight and Siren Alarm in Action
5.3 Түнкү көрүнүш
The camera automatically switches to night vision in low-light conditions. It supports both infrared (black and white) and color night vision, enhanced by its built-in spotlights.
Figure 5.4: Color Night Vision vs. IR Night Vision
5.4 Эки тараптуу аудио
Utilize the built-in microphone and speaker for real-time two-way communication. This feature is accessible through the NVR interface or the Jennov mobile application.
Figure 5.5: Real-Time Two-Way Audio
5.5 Remote Access (Jennov App)
Download the Jennov app on your smartphone or tablet to access live feeds, playback recordings, and manage camera settings remotely. The app supports multiple users and devices for screen sharing.
- Колдонмону жүктөө: Издөө "Jennov" in your device's app store.
- Түзмөктү жупташтыруу: Follow the in-app instructions to add your NVR system and connected cameras.
Figure 5.6: Remote Access via Jennov App
5.6 Сактоо параметрлери
Your Jennov P48 system offers multiple storage solutions for recorded footage:
- Pre-installed 1TB HDD: The NVR comes with a 1TB hard disk drive for local storage.
- Булуттагы сактагыч: Optional cloud storage plans are available for off-site backup (subscription may be required).
- TF картасы: The camera supports 8-256GB TF cards (Class 10) for local edge recording.
Figure 5.7: Available Storage Options
6. Техникалык тейлөө
Regular maintenance ensures the longevity and optimal performance of your security camera.
- Тазалоо: Periodically clean the camera lens with a soft, dry cloth to remove dust and smudges. Do not use harsh chemicals.
- Программалык камсыздоонун жаңыртуулары: Женновду текшериңиз website or app for available firmware updates for your NVR and cameras. Keeping firmware updated ensures access to the latest features and security enhancements.
- Кубат менен камсыздоону текшерүү: Кубат адаптери жана кабели бузулбагандыгын жана коопсуз туташтырылганын текшериңиз.
- Экологиялык текшерүү: For outdoor cameras, periodically check for obstructions to the camera's view, such as overgrown foliage, and ensure the mounting is secure.
7. Кыйынчылыктарды
If you encounter issues with your Jennov P48 Add-On Camera, refer to the following common problems and solutions.
| Көйгөй | Мүмкүн себеп | Чечим |
|---|---|---|
| Camera not displaying on NVR | No power; Out of wireless range; Not paired; NVR channel limit reached. | Check power connection; Relocate camera closer to NVR; Manually pair camera via NVR settings; Ensure NVR has available channels (max 8). |
| Сүрөттүн сапаты начар | Dirty lens; Low light conditions; Poor wireless signal. | Clean the camera lens; Ensure sufficient lighting or check night vision settings; Improve wireless signal by reducing distance or obstructions. |
| Кыймылды аныктоо иштебей жатат | Detection sensitivity too low; Detection zones not set correctly; Schedule not active. | Adjust motion detection sensitivity; Configure detection zones; Check motion detection schedule. |
| Cannot access camera on mobile app | NVR not connected to internet; App not configured correctly; Incorrect login credentials. | Ensure NVR is connected to your router via Ethernet; Verify app settings and NVR pairing; Double-check login information. |
| Эки тараптуу аудио иштебейт | Microphone/speaker blocked; Volume settings too low; App permissions. | Check for obstructions on microphone/speaker; Adjust volume settings on NVR/app; Grant necessary microphone permissions to the app on your mobile device. |
8. Техникалык шарттар
| Өзгөчөлүк | Деталь |
|---|---|
| Бренд | Дженнов |
| Модель номери | P48HC55-3-FAS |
| Байланыш технологиясы | Зымсыз |
| Видео тартуунун резолюциясы | 5MP Ultra-HD |
| Өзгөчөлүктөр | Easy to Install, Image Sensor, Night Vision, Video Recording, Weatherproof, Two-Way Audio, Motion Detection |
| Түс | Ак |
| Power Source | Электр зымдары |
| Элементтин өлчөмдөрү (L x W x Y) | 4.96 x 3.15 x 4.61 дюйм |
| Элемент Салмагы | 15.5 унция |
| Сунушталган Колдонуулар | Сыртта |
| Төмөн жарык технологиясы | Түнкү түс |
| Аба ырайына каршылык | IP66 |
| Иштөө температурасы | -20°Cден 60°Cге чейин |
9. Кепилдик жана колдоо
Jennov is committed to providing reliable products and responsive customer support. While specific warranty details are not provided in this manual, Jennov products typically come with a manufacturer's warranty covering defects in materials and workmanship.
9.1 Кардарларды колдоо
For technical assistance, troubleshooting, or warranty inquiries, please contact Jennov customer support through the following channels:
- Jennov Official Webсайт: Visit the official Jennov webКөп берилүүчү суроолор, колдоо ресурстары жана байланыш маалыматы үчүн сайт.
- Электрондук почта колдоо: Refer to your product packaging or the Jennov webатайын колдоо электрондук почта дареги үчүн сайт.
- Онлайн чат: Some regions may offer online chat support via the Jennov webсайт.
Please have your product model number (P48HC55-3-FAS) and purchase information ready when contacting support.
