1. Маанилүү коопсуздук нускамалары
- Колдонуудан мурун бардык нускамаларды окуп чыгыңыз.
- Ensure the appliance is properly assembled and locked before operation.
- Шире сыккычты шнуру же сайгычы бузулган абалда иштетпеңиз.
- Keep hands and utensils out of the feed chute during operation to prevent injury.
- Always unplug the appliance before cleaning or disassembling.
- Бул шайман тиричиликте гана колдонуу үчүн.
2. Продукт бүтүп калдыview
The AAOBOSI Cold Press Masticating Juicer is designed for efficient juice extraction from fruits and vegetables. Its slow masticating technology helps preserve nutrients and enzymes, providing a high yield of pulp-free juice.
Figure 2.1: The AAOBOSI Cold Press Masticating Juicer, shown with a glass of fresh juice and a cup for pulp.
3. Орнотуу жана чогултуу
The juicer features a 3-piece quick assembly design for ease of use. Follow these steps to assemble your juicer:
- Place the main motor base on a stable, flat surface.
- Align the juicing jug with the motor base. Ensure the cover is open during installation and removal.
- Press down and rotate the juicing jug clockwise until the lock symbol aligns, securing it into place. The machine will not operate if not properly locked.
Figure 3.1: Visual guide for proper assembly and locking of the juicer components.
Figure 3.2: Important warning: The cover must be open for correct assembly and disassembly of the chute.
4. Иштөө нускамалары
4.1 Ингредиенттерди даярдоо
The juicer features a 5.4-inch super wide feed chute, allowing you to insert whole fruits and vegetables without extensive pre-cutting. For optimal performance and to prevent jams, ensure fruits and vegetables are fresh and firm. Auto-cutting blades are designed to handle various produce effectively.
Figure 4.1: The wide feed chute accommodates whole fruits and vegetables, minimizing preparation time.
4.2 Шире сыгып алуу процесси
- Place the juice pitcher under the juice outlet and the pulp container under the pulp outlet.
- Turn on the juicer using the one-button operation.
- Slowly feed fruits and vegetables into the wide feed chute. The high-torque auger and auto-cutting blades will process the produce.
- The slow masticating process (60 RPM) extracts juice efficiently, separating pulp into the designated container.
- The 180W motor operates quietly at approximately 58dB.
Figure 4.2: Illustration of the high-torque auger mechanism for maximum juice yield.
Figure 4.3: The juicer operates at a low noise level of 58dB, ensuring a quiet juicing experience.
5. Тазалоо жана тейлөө
Regular cleaning ensures the longevity and optimal performance of your juicer. All removable parts are designed for easy cleaning.
5.1 Бөлүктөрдү бөлүп алуу жана тазалоо
- Unplug the juicer from the power outlet before disassembling.
- Disassemble the juicing jug components. Remember to open the cover for easy removal.
- Rinse all removable parts under running water. A cleaning brush is included to help remove pulp from the triple filter and other components.
- Some juicer parts are dishwasher safe, but hand washing is recommended for all components to ensure longevity and proper care.
- Ensure all parts are thoroughly dried before reassembly or storage.
Figure 5.1: The triple filter system ensures 99% pulp-free juice and requires regular cleaning.
Figure 5.2: Cleaning the juicer components with the included brush for efficient pulp removal.
6. Кыйынчылыктарды
| Көйгөй | Мүмкүн себеп | Чечим |
|---|---|---|
| Шире сыггыч күйбөйт. | Improper assembly or locking of components. | Ensure all parts, especially the juicing jug, are correctly aligned and locked into place. Refer to Section 3. |
| Ширенин аз чыгышы же ашыкча целлюлоза. | Insufficient quantity of produce; overly ripe or soft fruits/vegetables. | Use a sufficient amount of fresh, firm produce. Consider using slightly overripe fruits for maximum juiciness. |
| Juicer clogs or slows down. | Overfeeding produce or processing fibrous ingredients without proper preparation. | Feed produce slowly. For fibrous items like celery, cut into smaller pieces. Use the reverse function if available (check product for this feature). |
7. Продукттун спецификациялары
- Бренд: AAOBOSI
- Модель аты: ZM1907B
- Модель номери: UL-ZM1907B-BK
- UPC: 850074107644
- Түсү: Кара
- Өзгөчө өзгөчөлүгү: Бүтүндөй жемиштерди кайра иштетүү
- Продукциянын өлчөмдөрү: 13.39"D x 14.96"W x 7.68"H
- Бүткөн түрү: Мт
- Продукцияга кам көрүү боюнча көрсөтмөлөр: Hand Wash Only (Note: While some parts may be dishwasher safe, hand washing is recommended for all components to ensure longevity and proper care.)
- Тtage: 120V
- Элемент Салмагы: 8.34 фунт
- Материал: Plastic (Note: This refers to specific components; other parts like the auger and blades are metal.)
8. Кепилдик жана колдоо
AAOBOSI products are guaranteed for one year from the date of purchase. Additionally, we provide lifelong support and 24-hour premium service for our customers.
For any inquiries, technical assistance, or warranty claims, please contact our customer support team through the official AAOBOSI webсайт же сатуучуңуздун колдоо каналдары.
