Introduction
This manual provides detailed instructions for the proper setup, operation, and maintenance of your Geevon Indoor Outdoor Thermometer with Alarm Clock. Please read this manual thoroughly before using the device to ensure optimal performance and longevity.
Продукт бүттүview
The Geevon Indoor Outdoor Thermometer is designed to monitor temperature and humidity conditions both indoors and outdoors. Key features include:
- Large 3.8-inch LCD screen with bold digits for clear readability.
- Monitors indoor temperature and humidity, plus outdoor temperature from up to 3 remote sensors (one sensor included).
- Integrated alarm clock with a 5-minute snooze function.
- 10-second blue backlight for night viewing.
- Memory records for daily high/low temperature and humidity.
- Trend indicators for rising or falling temperature and humidity.
- Switchable Celsius/Fahrenheit and 12/24-hour formats.
- Battery-operated for portability, with options for tabletop or wall mounting.
The main display unit and its accompanying wireless remote sensor.
A comparison highlighting the Geevon thermometer's 3.8-inch large LCD display for easy readability versus a smaller 1.8-inch display.
Жайгашуу
1. Батареяны орнотуу
The main unit requires 2 AA batteries (not included). The remote sensor requires 2 AA batteries (not included). Ensure batteries are inserted with correct polarity.
2. Sensor Pairing
After inserting batteries into both the main unit and the remote sensor, the devices should automatically pair. If pairing does not occur, refer to the troubleshooting section.
3. Сенсордун жайгашуусу
Place the remote sensor in your desired outdoor location. For accurate readings and to prolong sensor life, ensure it is protected from direct sunlight and rain. The wireless transmission range is up to 200ft/60m in open air.
The main unit offers both tabletop and wall-mounting options for flexible placement.
A step-by-step guide on how to properly install and use the outdoor sensor for the Geevon thermometer, ensuring correct channel selection and placement.
Иштөө нускамалары
1. Display Overview
The large LCD displays indoor temperature and humidity, outdoor temperature, time, and weather trends. The top section shows outdoor readings, the middle section shows indoor readings, and the bottom section displays the time and date.
2. Убакыт жана дата орнотуу
Use the 'SET' button on the back of the unit to enter time setting mode. Use the 'UP' and 'DOWN' buttons to adjust values. Press 'SET' again to confirm and move to the next setting (e.g., 12/24-hour format, year, month, day).
3. Температура бирдигин тандоо (°C/°F)
Press the 'UP' button on the back of the unit to switch between Celsius and Fahrenheit.
4. Арткы жарык функциясы
Press the 'SNZ/LIGHT' button on the top of the unit to activate the 10-second blue backlight for easy viewаз жарык шарттарда.
5. Alarm Clock and Snooze
To set the alarm, press the 'SET' button until the alarm time flashes. Use 'UP' and 'DOWN' to adjust. Press 'ALARM' to turn the alarm ON/OFF. When the alarm sounds, press 'SNZ/LIGHT' for a 5-minute snooze.
6. МАКС/МИН жазуулар
Press the 'MEM' button to view the maximum and minimum temperature and humidity records. Long press 'MEM' for 3 seconds to clear the records.
7. Multiple Channel Monitoring
If using multiple remote sensors, press the 'CH' button to cycle through the channels (1, 2, 3). The display will show readings for the selected channel.
Деталдаштырылган view of the back of the main unit, indicating the Set, Lower, Upper, Signal, and Alarm buttons for various settings and functions.
This video demonstrates the basic setup and operation of the Geevon thermometer, including battery installation, setting the time, and switching between Celsius and Fahrenheit temperature units.
Техникалык тейлөө
To ensure accurate readings and extend the life of your thermometer:
- Түзмөктү жана сенсорду жумшак, d менен тазалаңызamp кездеме. Абразивдүү тазалагычтарды же эриткичтерди колдонбоңуз.
- Avoid exposing the main unit to direct moisture. The outdoor sensor should be placed in a sheltered location to prevent direct exposure to rain and harsh sunlight.
- Дисплейде батарейка аз индикатору пайда болгондо батарейкаларды алмаштырыңыз.
Проблемаларды чечүү
1. No Outdoor Temperature Reading
- Ensure the remote sensor batteries are correctly installed and not depleted. Try new batteries.
- Verify the main unit and sensor are within the effective transmission range (up to 200ft/60m in open air). Reduce obstacles between the units.
- Check that the sensor's channel switch matches the selected channel on the main unit.
- If the red light on the sensor does not flash after battery installation, try new batteries. If it still doesn't flash, the sensor may be faulty.
2. Туура эмес көрсөткүчтөр
- Ensure the outdoor sensor is not in direct sunlight or near heat sources, which can cause elevated readings.
- Так көрсөткүчтөр үчүн эки түзмөк тең орнотулгандан кийин кеминде 30 мүнөт турукташып калышы керек.
Техникалык шарттар
- Модель аты: 256300
- Модель номери: GE-256300-1-BK-WCA
- Бренд: Geevon
- Түсү: 256300 Кара
- Дисплей түрү: LCD экран
- Кубат булагы: Battery Powered (Main unit: 2 AA, Sensor: 2 AA - not included)
- Сырткы материал: Пластик
- Жогорку температура рейтинги: 50 градус
- Кайра колдонууга жарамдуулугу: Кайра заряддоого болбойт
- Камтылган компоненттер: Indoor thermometer, outdoor sensor, user manual
- Зымсыз берүү диапазону: Up to 200ft/60m (open air)
Кепилдик жана колдоо
For warranty information or technical support, please refer to the contact details provided with your product packaging or visit the official Geevon webсайт. Кепилдик дооматтары үчүн сатып алуу дүмүрчөгүңүздү сактаңыз.
