Introduction
The ATK 68 RX is a 65% esports keyboard engineered for precision and durability. It features advanced Hall Effect magnetic switches, which utilize non-contact actuation to eliminate physical wear, ensuring a longer lifespan and more consistent input compared to traditional mechanical switches.
This keyboard offers an exceptional level of customization with adjustable actuation for each key, ranging from 0.005 mm to 3.3 mm in precise 0.001 mm increments. This allows users to fine-tune sensitivity for both rapid gaming responses and accurate typing.
Constructed with a robust tray-mount chassis and an aluminum plate, the 68 RX provides superior keystroke stability and reduced vibration, enhancing the overall typing and gaming experience. The Cherry-profile frosted PC keycaps are designed to optimize RGB lighting diffusion while maintaining durability.
1-сүрөт: жогорудан ылдыйга view of the ATK 68 RX Hall Effect Gaming Keyboard.
Жайгашуу
To begin using your ATK 68 RX keyboard, follow these steps:
- Кутудан чыгаруу: Carefully remove all components from the packaging. Verify that you have the keyboard, USB-C cable, keycap & switch puller, M2 cross screwdriver, matching wrist rest, replaceable strap plate, strap, and matching add-on keycaps.
- Баскычтопту туташтыруу: Plug the USB-C end of the provided cable into the port on the keyboard and the USB-A end into an available USB port on your computer. The keyboard is designed for wired connectivity.
- Драйверди орнотуу (милдеттүү эмес, бирок сунушталат): For full customization and access to advanced features like adjustable actuation and preset switching, download and install the official ATK software driver from the ATK support webсайт.
Figure 2: Package contents of the ATK 68 RX keyboard.
Figure 3: USB-C port on the ATK 68 RX keyboard for connectivity.
Иштеп жатат
The ATK 68 RX keyboard offers a range of features designed to enhance your gaming and typing experience.
Негизги өзгөчөлүктөрү
- Hall Effect Switch Technology: The magnetic sensing mechanism provides ultra-high precision, faster response times, and an extended switch lifespan by eliminating physical contact points.
- Жөнгө салынуучу аракет диапазону: Customize the sensitivity of each key from 0.005 mm to 3.3 mm in 0.001 mm increments. This allows for optimal performance tailored to competitive gaming (e.g., rapid trigger) or precise typing.
Figure 4: Illustration of 0.005mm step precision.
- 65% / 68-Key Compact Layout: This layout retains essential keys and arrow keys while significantly saving desk space, which is ideal for gamers requiring quick mouse movements.
- Tray-Mount Structure with Aluminum Plate: This design ensures consistent keystroke stability, reduces unwanted vibration, and provides a more rigid and premium feel compared to standard plastic-mounted keyboards.
- Technical Components & Customization: The keyboard features Cherry-profile frosted PC keycaps that improve RGB diffusion. Users can choose between Wolf or Primordial magnetic switches based on their preference.
Figure 5: The compact size of the ATK 68 RX keyboard.
Ыңгайлаштыруу жана функциялар
- One-Click Preset Switch: Utilize the driver software to set up three customizable presets, allowing seamless switching between work and gaming modes.
- RGB жарыктандыруу: The keyboard features south-facing 16.8 million color RGB lighting with 22 pre-set lighting effects, offering extensive visual customization.
- Өркүндөтүлгөн функциялар: Supports RT (Rapid Trigger), DKS (Dynamic Key Stroke), MT (Macro Trigger), TGL (Toggle), adjustable deadzone, and comprehensive key remapping through the software.
- Innovative Wrist Rest Design: The detachable aluminum wrist rest provides ergonomic support and allows for custom DIY modifications.
Figure 6: Software interface for one-click preset switching.
Figure 7: Innovative wrist rest design with color options.
Техникалык тейлөө
Proper maintenance ensures the longevity and optimal performance of your ATK 68 RX keyboard.
- Жалпы тазалоо: Regularly use a soft brush or compressed air to remove dust and debris from between the keycaps. For surface cleaning, wipe with a slightly damp, мамыксыз кездеме. Катуу химиялык заттардан алыс болуңуз.
- Баскычка кам көрүү: The Cherry-profile frosted PC keycaps can be removed using the provided keycap puller for deeper cleaning. Wash keycaps with mild soap and water, then dry thoroughly before reattaching.
- Switch Care: Due to the Hall Effect magnetic switches, there is no physical contact wear. However, ensure no foreign objects enter the switch housing. If a switch needs replacement, use the provided switch puller.
- Кабелдик башкаруу: Зыяндын алдын алуу үчүн USB-C кабелин курч ийилип же ашыкча тартпаңыз.
Проблемаларды чечүү
If you encounter issues with your ATK 68 RX keyboard, consider the following common solutions:
- Баскычтоп жооп бербейт:
- USB-C кабели клавиатурага жана компьютерге бекем туташып турганын текшериңиз.
- Баскычтопту компьютериңиздин башка USB портуна туташтырууга аракет кылыңыз.
- Системага тиешелүү маселелерди жокко чыгаруу үчүн баскычтопту башка компьютерде сынап көрүңүз.
- Атайын ачкычтар иштебейт:
- Remove the keycap and visually inspect the switch for any obstructions.
- If you suspect a faulty switch, and you have spare switches, you may attempt to hot-swap the switch using the provided tool.
- Software Issues / Customization Not Applying:
- Ensure you have the latest version of the ATK software driver installed.
- Программаны жана/же компьютериңизди өчүрүп күйгүзүңүз.
- Check for any conflicting software that might interfere with keyboard functions.
- RGB жарыктандыруу көйгөйлөрү:
- Verify that the lighting settings in the ATK software are correctly configured.
- Баскычтоп USB портунан жетиштүү кубат алып жатканын текшериңиз.
If these steps do not resolve your issue, please refer to the support section for further assistance.
Техникалык шарттар
Detailed technical specifications for the ATK 68 RX Hall Effect Gaming Keyboard:
| Өзгөчөлүк | Description |
|---|---|
| Продукт аты | ATK 68 RX esports Hall Effect Keyboard |
| Түс параметрлери | White, Black, Pink |
| Которуу түрү | Wolf Switch / Primordial Switch (Magnetic Hall Effect) |
| Стабилизатор | V1 Demagnetized Stabilizer |
| RT (Rapid Trigger) Range | 0.005мм ~ 3.3мм |
| RT Step Precision | 0.001мм |
| Кечигип калуу | 0.08ms |
| Скандоо ылдамдыгы | 256K Гц |
| Добуш берүү көрсөткүчү | 8000 Гц |
| Баскыч капкактары | PC Frosted Keycaps (Cherry-profile) |
| Толгоо | Silicone Base Pad, Poron Foam, EPDM Foam, PET Film, IXPE Pad, Silicone Plate Foam |
| Билек таяныч материалы | CNC алюминий |
| Wrist Rest Color Options | Champagne Gold, Gray, Pink |
| Wrist Rest Finish | Anodized Sandblasting, Electrostatic Powder Coating |
| Жарыктандыруу | South-Facing 16.8M RGB with 22 Pre-set Lighting Effects |
| Positioning Plate | Aluminum Positioning Plate |
| Функциялар колдоого алынат | RT/DKS/MT/TGL/Adjustable Deadzone and Key Remapping |
| Байланыш | Зымдуу (USB-C) |
| Системанын шайкештиги | Windows / MacOS / Linux |
| Продукциянын өлчөмдөрү | 12.5"L x 4.5"W x 1.2"H (31.75 см x 11.43 см x 3.05 см) |
| Элемент Салмагы | 2 фунт (0.91 кг) |
| Өндүрүүчү | АТК |
| Модель номери | ATK 68 RX |
| Биринчи жеткиликтүү | 16-август, 2025-жыл |
Figure 8: Technical overview of the ATK 68 RX keyboard.
Кепилдик жана колдоо
ATK is committed to providing high-quality gaming gear. For information regarding product warranty, please refer to the warranty certificate included in your product packaging (Figure 2, item 2).
For technical support, driver downloads, or frequently asked questions, please visit the official ATK store or support page:
Visit the Official ATK Store on Amazon
You can also contact the seller, ATK Gaming Gears, directly through the Amazon platform for assistance.
