Carrera 30048 Digital 132 Race of The Champions Slot Car Race Track Set Instruction Manual

Introduction

This manual provides essential information for the setup, operation, and maintenance of your Carrera 30048 Digital 132 Race of The Champions Slot Car Race Track Set. Please read these instructions carefully before assembly and use to ensure safe and optimal performance.

Image: The complete Carrera Digital 132 Race of The Champions set, featuring the track layout, two Red Bull Racing cars, and the product packaging.

Коопсуздук маалыматы

Always supervise children during play. Ensure all connections are secure and the power supply is disconnected when not in use or during assembly/disassembly.

Кутуда эмне бар

Your Carrera Digital 132 Race of The Champions set includes the following components:

• Carrera Digital 132 Slot Car Racing Set
• Red Bull Racing RB20 "M. Verstappen, No.1" Slot Car
• Red Bull Racing RB20 "S. Perez, No.11" Slot Car
• Track sections for a 23.95-foot layout, including straightaways, curves, and crossover sections.
• 2.4 GHz Wireless+ Speed Controllers for precise throttle control.
• Control Unit for managing the race.
• Track supports and barriers.
• Электр камсыздоо.
• 2 AAA batteries (included for controllers).

Сүрөт: деталдуу view of all components included in the Carrera Digital 132 Race of The Champions set, laid out for inspection.

Жайгашуу

1. Тректи чогултуу:

   Carefully connect all track sections on a flat, stable surface. Ensure each piece clicks securely into place. Refer to the included layout diagram for suggested configurations or create your own. The track features exciting straightaways, sweeping curves, and crossover sections.



   Сүрөт: үстүнкү view of the assembled track, highlighting its 23.95-foot length and various sections.

2. Башкаруу блогунун туташуусу:

   Connect the control unit to the designated track section and then to the power supply. Plug the power supply into a suitable electrical outlet.
3. Контроллерди орнотуу:

   Insert the included AAA batteries into the wireless controllers. Pair the controllers with the control unit according to the instructions provided in the quick start guide (usually by pressing a pairing button on both the controller and control unit).



   Image: The two wireless controllers and their receiver, ready for connection and use.

4. Унааны жайгаштыруу:

   Place the Red Bull Racing RB20 slot cars onto the track. Ensure the guide keel of each car is properly seated in the track slot.



   Image: M. Verstappen's Red Bull Racing RB20 car, detailed and ready for racing.



   Image: S. Perez's Red Bull Racing RB20 car, showcasinанын татаал дизайны.

Иштөө нускамалары

The Carrera Digital 132 system allows for advanced racing features:

• Starting the Race: Once all cars are on the track and controllers are paired, activate the control unit to begin the race.
• Ылдамдыкты көзөмөлдөө: Use the wireless controllers to adjust the speed of your car. The 2.4 GHz Wireless+ technology ensures precise and responsive control.
• Lane Changing: Utilize the lane change sections on the track to overtake opponents or switch lanes strategically. This is a key feature of the Digital 132 system.
• Overtaking and Braking: The digital system allows for realistic overtaking and braking maneuvers, adding to the excitement of the race. Up to 6 cars can race simultaneously on the track.

Техникалык тейлөө

• Жолду тазалоо: Regularly clean the track rails with a lint-free cloth to ensure good electrical contact and smooth car operation. Avoid using abrasive cleaners.
• Унааны тейлөө: Check the car's guide keel and braids periodically for wear. Replace worn parts to maintain optimal performance. Keep the car's wheels and axles free from dust and debris.
• Сактагыч: When not in use, store the track and cars in a dry, dust-free environment. Disassemble the track carefully if storing for extended periods.

Проблемаларды чечүү

• Унаа кыймылдабай жатат:
  • Электр булагы туташып жана күйгүзүлгөнүн текшериңиз.
  • Check that the car's guide keel is correctly seated in the track slot.
  • Verify that the track rails are clean and free of obstructions.
  • Confirm the controller batteries are charged and the controller is paired.
• Үзгүлтүктүү кубаттуулук:
  • Inspect all track connections for secure fit.
  • Clean track rails to ensure consistent electrical contact.
• Car Derailed Frequently:
  • Reduce speed, especially in curves.
  • Check car tires for wear or damage.
  • Ensure track sections are perfectly flat and joined without gaps.

Техникалык шарттар

Кепилдик жана колдоо

For warranty information and customer support, please refer to the official Carrera website or contact your retailer. You can also visit the Carrera Store кошумча ресурстар жана продукт маалымат үчүн.
