Introduction
This manual provides detailed instructions for the assembly, operation, and maintenance of your DUMOS 9-Drawer Fabric Dresser. Please read all instructions carefully before beginning assembly and retain this manual for future reference. This dresser is designed as a versatile storage solution for various rooms, including bedrooms, closets, entryways, and guest rooms.
The dresser features a sturdy metal frame, a durable wooden top, and nine spacious fabric drawers. It is designed for stability and ease of use.
Коопсуздук маалыматы
- Чийип кетпеш үчүн шкафты дайыма жумшак, таза бетке чогултуңуз.
- Колдонуудан мурун бардык бурамалар бекем бекитилгенин текшериңиз. Ашыкча бекемдебеңиз.
- Use the provided anti-tipping accessories to secure the dresser to a wall, especially if children are present. This prevents accidental tipping and potential injury.
- Do not exceed the maximum weight capacity for the top board or individual drawers.
Бөлүктөр тизмеси
Before assembly, verify that all parts are present and undamaged. Refer to the diagram below for identification.
Figure 1: All components included in the DUMOS 9-Drawer Fabric Dresser package.
- Кадрлар: Left Frame (A), Right Frame (B), Middle Frame (C), Top Frame (D)
- Риверс: Top Cross (E), Bottom Cross (F)
- Рамкалар: Right Slats (R), Left Slats (L)
- такталар: Top Board (P), Drawer Base Board (G)
- Тарткычтар: Big Drawer (K), Small Drawer (N)
- Аппараттык камсыздоо: Drawer Handle (6), Screws (2), Screws (4), Expansion Tube (5), Screws (5)
Орнотуу нускамалары
Follow these steps to assemble your DUMOS 9-Drawer Fabric Dresser. It is recommended to have two people for assembly.
Video Guide: Dresser Assembly
Video 1: Step-by-step assembly guide for the DUMOS 9-Drawer Dresser.
Кадамдык Ассамблея
- Attach Frames to Top Board: Fix the Right-Left Frames (A & B) to both ends of the Top Board (P). Fix the Top Frame (D) to the middle of the Top Board (P) using Screws (2) * 6. Ensure the drawer holes on Frames (A), (B), and (D) face the same direction.
- Install Middle Frame: Install the other side of Middle Frame (C) * 1 to the Top Cross (E) * 2 using Screws (2) * 2. Ensure the drawer holes on Frames (A), (B), and (C) face the same direction.
- Install Top Crossbars: Install Top Cross (E) * 2 to the top of Frames (A, B & D) with Screws (2) * 8.
- Install Bottom Crossbars: Install Bottom Cross (F) * 2 to the Frames (A, B & C) with Screws (2) * 6.
- Install Adjusting Feet: Install Adjusting Foot (1) * 4 to the Side Frames (A & B).
- Assemble Drawer Slats: Assemble the Left Slats (L) * 9 and Right Slats (R) * 9 bars to the frame (A, B & C & D). Tighten screws AFTER Drawer sliders are assembled.
- Тарткычтарды чогултуу: Place Drawer Base Board (G) * 3 into the expanded Small Drawer (N) * 3. Install the Drawer Handle (6) * 3 with Screws (4) * 6. Install the three Small Drawers (N) * 3 in the same way. Repeat for Big Drawers (K) * 6 and Drawer Base Board (H) * 6, installing Drawer Handle (6) * 6 with Screws (4) * 12.
- Салгычтарды салуу: Put the installed Small Drawers (N) * 3 and Big Drawers (K) * 6 into the frame in turn.
- Дубалга бекитүү (милдеттүү эмес, бирок сунушталат): If you need to fix the dresser to the wall, drill holes in the wall with an electric drill, then insert Expansion Tube (5) * 2 and fix the dresser with Screws (5) * 2.
Figure 2: Securing the main frame components to the top board.
Figure 3: Attaching the middle frame to the top crossbars.
Figure 4: Attaching the plastic drawer slats to the metal frame.
Figure 5: Steps for assembling the fabric drawers.
Figure 6: The fully assembled DUMOS 9-Drawer Fabric Dresser.
Иштөө нускамалары
тартмаларды колдонуу
- Суурманы ачуу үчүн тутканы акырын тартыңыз.
- Сумканы жабуу үчүн, аны толугу менен отурганга чейин кайра рамканын ичине түртүңүз.
- Avoid forcing drawers open or closed to prevent damage to the fabric or frame.
- Distribute items evenly within the drawers to maintain balance and prevent strain on the drawer slides.
Салмак сыйымдуулугу
The wooden top board has a maximum capacity of 66 pounds. Each fabric drawer has a maximum capacity of 13 pounds. Do not exceed these limits to ensure the longevity and stability of the dresser.
Figure 7: Dresser dimensions and weight capacity information.
Техникалык тейлөө
Тазалоо
- Wooden Top: Wipe with a dry cloth to remove dust and spills. Avoid abrasive cleaners or excessive moisture.
- Металл рамка: жумшак менен сүртүп, гamp дат баспаш үчүн дароо кургатыңыз.
- Кездеме тартмалары: Жумшак жуугуч жана жарнама менен тактарды тазалаңызamp кездеме. Толугу менен кургатыңыз. Кир жуугуч машинада жуубаңыз же кургатуучу машинада кургатпаңыз.
Жалпы кам көрүү
- Periodically check all screws and connections to ensure they remain tight. Tighten as needed.
- Avoid placing hot items directly on the wooden top. Use coasters or protective pads.
- Keep the dresser away from direct sunlight and excessive humidity to prevent material degradation.
Проблемаларды чечүү
Эгерде сиз шкафыңызда кандайдыр бир көйгөйлөргө туш болсоңуз, төмөнкү кеңири таралган көйгөйлөрдү жана чечимдерди караңыз:
| Көйгөй | Мүмкүн себеп | Чечим |
|---|---|---|
| Шкафтын ичи солкулдап же туруксуз сезилет. | Бурамалар бошоп калган; пол тегиз эмес. | Tighten all assembly screws. Adjust the leveling feet on the bottom of the frame to stabilize. Ensure the dresser is placed on a flat surface. |
| Тарткычтар жылмакай жылбайт. | Drawer base board not fully inserted; items obstructing movement; plastic sliders misaligned. | Ensure the drawer base board is fully inserted and flat. Check for any items inside the drawer or on the frame that might be blocking movement. Verify that the plastic sliders are correctly installed and not damaged. |
| Drawer handle is loose. | Handle screws are loose. | Tighten the screws that secure the handle from inside the drawer. |
| Жок же бузулган бөлүктөрү. | Өндүрүштүк кемчилик же жеткирүү зыяны. | Do not attempt to force assembly. Contact DUMOS customer support for replacement parts. |
Техникалык шарттар
| Өзгөчөлүк | Деталь |
|---|---|
| Бренд | DUMOS |
| Модель аты | Уктоочу бөлмө үчүн шкаф |
| Модель номери | KACAB-AS9BC-BKWD-01 |
| Продукциянын өлчөмдөрү | 11.8"D x 39.4"W x 39.4"H |
| Түс | Кара жыгач |
| Бөлмө түрү | Уктоочу бөлмө |
| Материал | Engineered Wood (Top Board), Fabric (Drawers), Metal (Frame) |
| Аяктоо түрү | Жыгач |
| Тартмалардын саны | 9 (3 кичинекей, 6 чоң) |
| Элемент Салмагы | 29 фунт |
| Top Board Capacity | 66 фунт |
| Тарткычтын сыйымдуулугу | Ар бир тартма үчүн 13 фунт |
| Ассамблея талап кылынат | Ооба |
| Продукцияга кам көрүү боюнча нускамалар | Кургак чүпүрөк менен сүртүңүз |
| UPC | 715569016347 |
Кепилдик маалымат
DUMOS products are manufactured with quality and care. This product comes with a standard manufacturer's warranty against defects in materials and workmanship. For specific warranty terms, duration, and to make a claim, please retain your proof of purchase and contact DUMOS customer support. The warranty typically covers manufacturing defects and does not cover damage resulting from improper assembly, misuse, neglect, or normal wear and tear.
Кардарларды колдоо
If you have any questions, require assistance with assembly, or need to report missing or damaged parts, please contact DUMOS customer support. Our team is dedicated to providing prompt and helpful solutions.
- Электрондук почта: Refer to your product packaging or purchase documentation for the most current contact email.
- Онлайн колдоо: Visit the official DUMOS webсайт же сиз продуктуну сатып алган чекене сатуучунун колдоо барагы.
Please have your model number (KACAB-AS9BC-BKWD-01) and proof of purchase ready when contacting support.
